Joston Glue Melting Tank Hot Glue Vacuum Glue Dissolve Mixer Machine

Product Description

Detailed Photos
Product Description Usage
Gelatin Melting Tank is the main equipment in the production process of capsulized glue.the agitator stirring mode adopts bidirectional multi-layer split-flow stirring.which had the advantages of uniform material stirring and accelerating sol dissolution.
Gelatin Melting Tank heating model adopts water bath thermal resistance heating,which had fast heating speed and uniformity,stable temperature control,optimum gel temperature,which can be improved gel quality and shortened gel time.
Character
Glue melting tank belongs to the technical field of soft (hard) capsule pharmaceutical industry, which is made of stainless steel material .
Glue melting tank tank body adopts three-layer closed structure, including inner tank, heating jacket layer and heat preservation insulation layer.The mixing assembly is composed of a looper connected mixing slurry for rotation, a manhole (feeding port) for quick opening and quick installation, and the device on the tank is composed of a thermometer, a vacuum gauge and other instruments for observation and control.
Glue melting tank has fast heating, strong constant temperature performance, stable vacuum performance and stable operation.
Glue melting tank is bright and smooth inside and outside surface, convenient for disassembly, maintenance and cleaning.
Glue melting tank can accelerate the speed of dissolving glue liquid, improve the liquid medium of glue liquid, and stabilize the uniformity of glue liquid. It is a special supporting equipment for the capsule medicine industry as the homogenization of glue (ingredient), vacuum stirring and dissolving glue liquid. Product Parameters Technical description

item	HJG-500	HJG-800	HJG-1000	HJG-1500	HJG-2000
Volume L	500	800	1000	1500	2000
Motor power KW	3/1.5	5.5/2.2	5.5/2.2	7.5/3	11/4
Mixer speed RPM	25/35 (can be adjustable)
Material	304/316L
Shell work pressure MPa	-0.09--0.1
Jacket pressure MPa	According to URS
Fittings	Electrical control panel,bottom discharge valve,vacuum gauge,temperature sensor,manhole,sight glass,sight light,vent filter etc

Remark :above model just for reference ,we can do according to client's URS Company Profile
FAQ & SERVICE
1.What about your factory?
Our factory is located in Wenzhou city ,Zhejiang Province and have more than 15 years experience on machinery making.
2.How will your company control the equipment quality ?
We have a qualified expert team ,we will inspect every production proceed .also Machines will be tested in our plant before shipment .
3.How long the warranty will be?
We provide 1 years warranty for the machine running ,but we will afford whole -life service for the machine .
4.Which kind payment do your company do now ?
We accept Western Union, T/T ,D/P,D/C and irrevocable L/C payable etc.
5.Can we become your distributor in our country?
Yes, we very welcome you! More details will be discussed if you are interested in being our agent.
6.Why we choose "JOSTON "?
1. We enhance the reliability of product's quality and working life .
2. We decrease the consumption cost of the product in the ruuning.
3. We improve research personnel's ability to deliver a creative design;
4. We use leading technologies in our product development and innovation, and thereby increase the competitive advantage of products.
7.Do you supply installation equipment in oversea?
Yes, if need, we can send our engineer to your plant to help you do installation and commission.
8.How can we know the order production status ?
We will arrange the person to take photo or video during manufacturing in every week to make you to know the production status.When goods are finished,we will take detailed photos or video for your checking ,after approve ,then we will arrange shipment .also you can arrange FAT in our plant when the goods is ready here
9.what is kind service do you offer before making order ?
1.according to your company URS ,we will make the design drawing accoridingly.
2.after your company approved drawing ,we will make quotation.
3. final we make agreement on payment terms ,delivery time ,package ,shipment etc.
10.how about your company after-sale serivce ?
1. We provide long-term after-sale service.
2. we can do installation and commission for the equipment in your plant if necessary .
3. Meanwhile, you can call or e-mail us to consult on any relevant question since we have a special line for after-sale service. Alternatively, you can communicate on-line with us to solve any problem.
We have established some overseas agent office to make the after-sales serivce already ,so it can will be service client in fast response .also in our headquarter service team ,there is a expert team which can support client in 7*24 hours .
1. Customer inquiry and consultation (URS documents)
2. Confirmation of treatment plan (DQ documents &PID Drawing)
3.Quotation offer with the technolgy document (Quotation PI )
4.Engineering and Manufacturing (Prodcution &Quality inspection )
5. Product inspection (FAT documents)
6. Delivery arrangement and loading work (full set Shipment documents)
7. After-sales service (OQ,PQ ,SAT documents)

---
