US$560.00-650.00
|
87 Pieces
(MOQ)
|
Basic Info.
Certification
CCC, EEC, CQC
Braking Mode
Front Disc Brake Drum
Cooling Method
Air Cooling
Packing Status
Carton with Iron Bracket
Transport Package
Steel Structure Cover Carton
Production Capacity
300000pieces/Year
Product Description
Product Parameters
| Displacement | 106.7ml | 127ml |
| Engine | 1 Cylinder, 4 Stroke | 1 Cylinder, 4 Stroke |
| Bore & Stroke | 52.4×49.5 | 54×55.5 |
| Cooling System | Air Cooled | Air Cooled |
| Compression Ratio | 9.0:1 | 8.7:1 |
| Fuel feed | 90# | 90# |
| Max Power( Kw/rpm) | 5.1/8000 | 6.4/8300 |
| Max Torque(N.M/rpm) | 7.2/5000 | 9.5/5000 |
| Max Speed | 80kmph | 118 kmph |
| Ground clearance | 142mm | 142mm |
| Fuel consumption | 1.1L/100KM | 1.2L/100KM |
| Ignition | CDI | CDI |
| Transmission | Belt | Belt |
| Fuel tank capacity | 12L | 12L |
| Starting System | Electric+kick start | Electric+kick start |
| Front Brakes | Disc brake | Disc brake |
| Rear Brake | Drum brake | Drum brake |
| Front wheels | Alum 120/70-12 | Alum 120/70-12 |
| Rear wheels | Alum 130/70-12 | Alum 130/70-12 |
| Wheel Base | 1108 mm | 1108mm |
| Seat Height | 745mm | 745mm |
| Net Weight | 86kg | 175kg |
| Gross Weight | 92kg | 187kg |
| Packing type | Steel + Carton | Steel + Carton |
| size | 1620×570×850 mm | 1620×570×850 mm |
| 40' HQ container | 87units | 87units |
Detailed Photos
Exhibition:
FAQ
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Q1: Can I have a sample order for your products?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What about the lead time?
A:Sample needs 20 days, mass production needs about 6 weeks for order quantity more than one container.
Q3: What kind of certificates could you provide for the your vechiles.
A: CE, ISO....
Q4: Do you offer charger for battery?
A: Yes, we do. We supply all parts for maintainance.
Q5:How long is the warranty do you have?
A: 1 year or 6000km for main parts such as wheel rim, engine, shock absorber etc.
>>
