Acid Resistant Digital Pressure Gauge for Chemical Applications and Reliability

Product Description

Precision-Crafted Sheet Metal Stamping Parts - Your Premier Stainless Steel Stamping Parts Manufacturer

Basic Info.
Application:	General pressure gauge is suitable for measuring the pressure of no explosion risk, no crystallization, no solidification and no corrosion effect on steel, copper alloy liquid, steam and gas and other media
Place of origin:	Nanpi County, Cangzhou City, Hebei province
Productive capacity:	500,000 pieces/month
measuring range
model number	measuring range MPa,									precision(%)
y-40(Z)	0~0.6,1,1.6,2.5,4,6,10, 16,25,-0.1~0									2.5
Y-60(Z/ZT)	0~0.6,1,1.6,2.5,4,6,10, 16,25,-0.10,0.06,0.15,0.3, 0.5,0.9,1.5,2.4									2.5
y-100(Z/ZT) Y-150(2/ZT)	0~0.1,0.16,0.25,0.4,0.6, 1,1.6,2.5,4,6,10,16,25, 40,60,-0.1~0,0.06,0.15, 0.3,0.5,0.9,1.5,2.4,									1.6
Y-200 Y-250	0~0.6,1,1.6,2.5,4,6									1.6
Note: 1, the model in brackets indicates optional, can refer to the model diagram. 2, the range in addition to MPa can also choose psi, bar, mmHg
geometric dimensioning
model number	a	b	b.	b,	D1	D2	e	f	G	H	SW
Y-40	8.5	23	23	58	40	40		8.5	M10×1.0	58	11
Y-40Z	0	23	23	44	40	61		0	M10×1.0	44	14
Y-60	10.5	28	28	56	60	99		10.5	M14X1.5	56	22
Y-60Z	0	28	28	56	60	149		0	M14×1.5	56	22
Y-60ZT	0	28	28	56	60	40	24	0	M14×1.5	56	11
Y-100	16	42	42	90	100	61		16	M20×1.5	90	14
y-100ZT	24	43	43	83	100	99	25	24	M20×1.5	83	22
y-150	16	44	44	116	150	149		16	M20X1.5	116	22
Y-150ZT	35	45	45	85	150	40	27	35	M20×1.5	85	11
Y-200	16	46	46	140	200	61		16	M20×1.5	140	14
Y-250		60	60	170	250	99			M120X1.5	170	22

---
