Save 30% Energy with Our Briquette Press

Product Details

Product Details

Product Description

Product Description
Save 30% Energy with Our Briquette Press
Save 30% Energy with Our Briquette Press Introduction:
Save 30% Energy with Our Briquette Press is mainly used to briquette charcoal leftover, small pieces of charcoal, charcoal waste, etc. and make them be fully used to increase its economic value. The final briquette shape and size both can be customized from 25-60mm with oval, pillow and square shape as well as other favorite shapes in market. according to special requirement. In addition, the raw material range is very widely, like coal powder, fertilizer, salt, iron powder, and gypsum, chrome, copper, etc.
Save 30% Energy with Our Briquette Press Structure:
(1) We offer three types of pressure: spring disc, wedge block and hydraulic
Hydraulic type has larger pressure, even some uneasy shaping materials, such as dry powder, fertilizer, salt, etc, can also press in good shape, the pressure can be adjusted according to different raw material.
(2) Because charcoal powder is just a little light, easy to be molded. The roller material adopts 65Mn is enough. Normally, this kind of roller can use 8-10 month.
(3) We also produce four-rollers Save 30% Energy with Our Briquette Press: in order to reduce density between charcoal powder and make best quality charcoal briquettes, we design four rollers charcoal briquette machine, which can press charcoal powder two times.
Save 30% Energy with Our Briquette Press Technical Parameter:
XM Series Coal Briquetting Machine
ModelReducerRatioRoller Size(mm)Main Shaft Speed(r/min)Matched Power(kw)Capacity(t/h)Pressure Type
XM290ZQ3501:31.5290*20012-145.50.9-1.0Constant Pressure
XM360ZQ3501:31.5360*25012-147.51.5-2.0Constant Pressure/Hydraulic Pressure
XM400ZQ4001:31.5400*25012-147.52.5-3.5
XM430ZQ4001:31.5430*25012-14113.5-4.5
XM500ZQ65040.17500*47010-12377.5-8.5
XM650ZQ85040.17650*4709-11459-10
XM750ZQ100040.17750*5709-119013-14
XM850ZQ125050850*5708-1011015-17
Remarks: Above capacity is based on material specific gravity 0.8, briquette size: φ50*33mm
Roller material is 65Mn, high chrome alloy and 9Cr2Mo
According to different material adjust machine parameter to meet customer production

KF Series Mineral Powder Briquetting Machine
ModelReducerRatioRoller SizeMain Shaft Speed(r/min)Matched Power(kw)Capacity(t/h)Pressure Type
KF500-371-280ZQ50040.17370*2808-10116.5-7.5Constant Pressure/Hydraulic Pressure
KF650-500-300ZQ65040.17500*3008-10378.5-9.5
KF850-650-300ZQ85040.17650*3008-105510.5-11.5
KF1250-750-350ZS125050750*3507-911013.5-14.0
KF1450-850-350ZS145050850*3507-913215.0-16.0
KF560-1000-350ZSY560501000*3507-915017.0-20.0
Remarks: Above Capacity is based on material specific gravity 2, briquette size:φ50*33mm
Roller material is 65Mn, high chrome alloy and 9Cr2Mo.
According to different material adjust machine parameter to mmet customer production

YHG Series Dry Powder High Pressure Briquetting Machine
ModelYHG-0.5YHG-1.5YHG-3.0YHG-5.0YHG-8.0YHG-10.0
Roller Diameter(mm)φ299φ367φ522φ738φ760φ858
Roller Width(mm)180183196210225300
Capacity(t/h)0.51.2-1.42.5-3.04.5-5.57.5-8.58.0-9.5
Main ReducerZQ650ZQ850ZS1250ZS1450ZS1650ZS1650
Main Motor18.537557590-110110-132
Pre-pressure Motor(kw)7.5111518.518.522
Pre-pressure ReducerWHC-125WHC-160WHC-200WHC-210WHC-210WHC-250
Remarks: Above capacity is based on material specific gravity 1.3, briquette size: φ35*30*20mm
Roller material adopts 9Cr2Mo
Pre-pressure motor is speed motor
