2 Faces Indented Prestressed Steel Wire with Ellipse Indentations

Product Description

Indented PC Wire = indentation surface PC wire
Triple indent - indentation type T1, Belgian indent - indentation type T2
Product Standards: BS5896-2012, EN10138-2: 2011 and GB/T5223-2014
Description: steel wire for pre-stressed concrete (PC Wire), steel wire for pre-stressing of concrete (PC Wire), pre-stressed concrete wire (PC Wire), pre-stressing of concrete wire (PC Wire), low relaxation wire (LR Wire), stress relieved wire (SR Wire), high tensile steel wire (HTS Wire), high tensile strength wire (HTS Wire), high carbon wire (HC Wire), high carbon steel wire (HCS Wire)
Standards: ASTMA421-2010, ASTM A648, ASTM A821, ASTM A881, AASHTO M 204-2014, AS 1310:1987, ABNT NBR7482, BS5896-2012, CSN 42 6448-1988, EN10138-2: 2009, EN ISO 15630-2019, GB/T5223-2014, IS 1785 Pt.1-1983, ISO 6934-1991, JISG3536-2014, JIS G 3538-1994, KSD7002-2019, KSD ISO6934-2014, NEN3868-2001, NF A03-720-1:2010, SNI 1155-2011, SIS SS 21 25 22-1987, TCVN 6284-1997, TIS 420-1997, UNE36094-1997, UNE 36814:2003 IN
Diameter: 2.5mm, 2.64mm, 2.8mm, 3.0mm, 3.2mm, 3.4mm, 3.8mm, 4mm, 4.2mm, 4.8mm, 5mm, 6mm, 7mm, 7.5mm, 8mm, 9mm, 10mm, 11mm, 12mm
Raw Material: High carbon steel wire rod SWRH77B, SWRH82B and other grade.
Shape: plain/smooth surface, spiral/helical ribs/ribbed surface, indented
Tensile Strength: 1470MPa, 1570Mpa, 1670Mpa, 1770Mpa, 1860MPa etc
Relaxation: Initial load at 70% breaking low, Relaxation on 1000 hours: 2.5% max
Lo=200mm, Min Elongation at breakage: 3.5% min
Packing Method: in rolls or in bundles, by baling strips and plastic films
Packing Weight: 700-900ks, 1000-1300kgs, 2200-2500 kgs
Application: electricity poles, railway sleeper, subway track board, concrete piles, beams, girders, slabs, hollow floor board, double-T board, PHC, PPCP, cement pipes, mattress etc.

Diameter (mm)	2.5 3.0 3.2 3.4 3.8	4.0 4.8 5.0 6.0 7.0	7.5 8.0 9.0	10.0 11.0 12.0
Grade (MPa)	1770-1860	1670-1770	1570-1670	1470-1570

Technical Specifications and Parameters
Diameter (mm)	Tolerance (mm)	Tensile Strength Min (MPA)	Yield Strength Min (σp0.2/MPA)	Elongation at breaking load (Lo=200mm) Min (%)	Bending Times Min	Bending Radius R/mm	Relaxation Value
							The relaxation at 1000h (Initial load to 70% of breaking load) Max (%)
3.0	±0.04	1670 1770 1860	1470 1560 1640	3.5	4	15	2.0
3.2
3.4
3.8

---
