Intelligent Concrete Impemeability Test Machine

US$1.00-30,000.00 1 Set (MOQ)

Basic Info.

Model NO.
CXIC-V
Type
Permeability Test
Display
Computer
Weight
>2000Kg
Power Source
AC220V
Max. Specimen Numbers
5 Groups (30 PCS)
Measuring Range
0-1.2MPa
Sealing Method
Airtight Sealing Type
Total Power
3kw
Dimension
1700×960×1935mm
Transport Package
Plywooden Case
Origin
Zhejiang, China
HS Code
9024800000
Production Capacity
20 Sets Per Month

Product Description

CXIC-V intelligent concrete impemeability test machine
Application
It is suitable for testing the impermeability performance of concrete, with simple operation and reliable results, it can do automatically sealing, detecting, judging, and extruding.
Standard
GB/T 50082-2009 Standard for test methods of long-term performance and durability of ordinary concrete
DL/T 5150-2017 Test code for hydraulic concrete
Characteristics Five groups of experiments (30 pcs specimens) are conducted at once, with each group independent of each other, saving time and efficiency Small footprint, high space utilization, no foundation installation, easy to place. Designed in accordance with ergonomics, the specimen is placed at an appropriate height, reducing labor intensity and improving work efficiency Using automatic sealing method, after placing the test block, the test can be conducted directly Adopting mechanical locking, with high safety performance Equipped with test block detection function, automatically determining the presence of test blocks Automatic detection function for minimal water seepage Can be unmanned 24 hours a day, reducing labor costs. It can automatically generate test reports, directly export raw data, and has the function of automatically uploading data to the internet. You can view the experimental situation and results in real-time through the mobile WeChat mini program. Equipped with warning and prompt functions such as fault information, detailed information can be viewed by clicking on the list
Main technical parameters
Model CXIC-V
Number of experiments 5 groups (1 group each layer, total 30 specimens), can be tested in single group
Test mode Stepwise pressurization method, Permeability height method
Measuring range 0-1.2Mpa
Force relative error ≤±0.01Mpa
Force maintain error ≤±0.02Mpa
Minimum display division value of water pressure 0.001MPa
Sealing method Airtight sealing type
Maximum sealing pressure 1.6Mpa
Sealing pressure resolution 0.01Mpa
Permissible range of test specimens φ175±2mm/φ185±2mm/150±5mm
Computer 21.5-inch capacitive touch screen
Water pump 220V 48W×6
Total power 3kW
Power supply 220V
Dimension 1700×960×1935mm
Weight About 2300kg
