Product Description
Product Description
DescriptionPower Supply DC supply 4.5V~5.5V typically 5V, VBAT: 3.3V at J202 (U)SIM Interface USIM/SIM card (6 pins) connector with push loading USIM/SIM card: 3V and 1.8V Audio Interface Used for earphone and handset UART Interface COM-serial interface for data communication (default 115200bps)Max. baud rate: 460800bps USB Interface USB 2.0 Signal Indication 2 LEDs are available for signal indication Physical Characteristics Size: 94mm × 58mmOverviewEC25 Mini PCIe is a series of LTE category 4 module adopting standard PCI Express® Mini Card form factor (Mini PCIe). It is optimized specially for M2M and IoT applications, and delivers 150Mbps downlink and 50Mbps uplink data rates.EC25 Mini PCIe contains 11 variants: EC25-E Mini PCIe, EC25-EU Mini PCIe, EC25-EUX Mini PCIe, EC25-J Mini PCIe, EC25-A Mini PCIe, EC25-V Mini PCIe, EC25-AF Mini PCIe, EC25-AFX Mini PCIe, EC25-MX Mini PCIe, EC25-AU Mini PCIe and EC25-AUX Mini PCIe. This makes it backward-compatible with existing EDGE and GSM/GPRS networks, ensuring that it can be connected even in remote areas devoid of 4G or 3G coverage.EC25 Mini PCIe supports Qualcomm® IZat™ location technology Gen8C Lite (GPS, GLONASS, BeiDou/Compass, Galileo and QZSS). The integrated GNSS greatly simplifies product design, and provides quicker, more accurate and more dependable positioning.A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB serial drivers for Windows 7/8/8.1/10, Linux, Android/eCall*) extend the applicability of the module to a wide range of M2M applications such as industrial router, industrial PDA, rugged tablet PC, video surveillance and digital signage.www.hurryup.en.china.cnKey Benefits● LTE category 4 module optimized for broadband IoT applications● Worldwide LTE, UMTS/HSPA(+) and GSM/GPRS/EDGE coverage● Standard PCI Express® Mini Card form factor (Mini PCIe) ideal for manufacturers to easily integrate wireless connectivity into their devices● MIMO technology meets demands for data rate and link reliability in modem wireless communication systems● Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environmentEC25-E Mini PCIeLTE-FDD: B1/B3/B5/B7/B8/B20LTE-TDD: B38/B40/B41WCDMA: B1/B5/B8GSM/EDGE: B3/B8Embedded GNSS: OptionalRegion: EMEA/South Korea/ Thailand/IndiaCarrier:Vodafone/Deutsche Telekom/ SKT/ Telefónica/KT*/ LGU+*Regulatory:GCF/ CE/ KC/ NCC/ RCM/ FAC/ NBTC/ ICASAOthers:WHQLEC25-EU Mini PCIeLTE-FDD: B1/B3/B7/B8/B20/B28ALTE-TDD: B38/B40/B41WCDMA: B1/B8GSM/EDGE: B3/B8Embedded GNSS: OptionalRegion: EMEA/ThailandCarrier:Deutsche Telekom/ British TelecomRegulatory:GCF/ CE/ NCC/ RCMOthers:WHQLEC25-EUX Mini PCIeLTE-FDD: B1/B3/B7/B8/B20/B28ALTE-TDD: B38/B40/B41WCDMA: B1/B8GSM/EDGE: B3/B8Embedded GNSS: OptionalRegion: EMEA/ThailandRegulatory:GCF/ CE/ NCC/ RCMOthers:WHQLEC25-J Mini PCIeLTE-FDD: B1/B3/B8/B18/B19/B26LTE-TDD: B41WCDMA: B1/B6/B8/B19GSM/EDGE: /Embedded GNSS: OptionalRegion:JapanCarrier:NTT DOCOMO/ SoftBank/ KDDIRegulatory:JATE/ TELECOthers:WHQLEC25-A Mini PCIeLTE-FDD: B2/B4/B12LTE-TDD: /WCDMA: B2/B4/B5GSM/EDGE: /Embedded GNSS: OptionalRegion: North AmericaCarrier:AT&T/T-Mobile/ Rogers/ TelusRegulatory:FCC/ IC/ PTCRBOthers:WHQLEC25-V Mini PCIeLTE-FDD: B4/B13LTE-TDD: /WCDMA: /GSM/EDGE: /Embedded GNSS: OptionalRegion: VerizonCarrier:VerizonRegulatory:GCF/ FCCOthers:WHQLEC25-AF Mini PCIeLTE-FDD: B2/B4/B5/B12/B13/B14/B66/B71LTE-TDD: /WCDMA: B2/B4/B5GSM/EDGE: /Embedded GNSS: OptionalRegion:North America FirstNetCarrier:Verizon/ AT&T/ T-Mobile/ U.S. Cellular/ Rogers/ TelusRegulatory:GCF/ FCC/ PTCRB/ ICOthers:WHQLEC25-AFX Mini PCIeLTE-FDD: B2/B4/B5/B12/B13/B14/B66/B71LTE-TDD: /WCDMA: B2/B4/B5GSM/EDGE: /Embedded GNSS: OptionalRegion: North America FirstNetCarrier:Verizon*/ AT&T*/ T-Mobile*/U.S. Cellular*/ Rogers*/ Bell*/ Telus*Regulatory:GCF/ FCC/ PTCRB/ ICOthers:WHQLEC25-MX Mini PCIeLTE-FDD: B2/B4/B5/B7/B28/B66LTE-TDD: /WCDMA: B2/B4/B5GSM/EDGE: /Embedded GNSS: NRegion: MexicoRegulatory:FCC/ PTCRB/ IFETELOthers:WHQLEC25-AU Mini PCIeLTE-FDD: B1/B2①/B3/B4/B5/B7/B8/B28LTE-TDD: B40WCDMA: B1/B2/B5/B8GSM/EDGE: Quad-bandEmbedded GNSS: OptionalRegion: Latin America/Australia/New ZealandCarrier:Telstra*Regulatory:GCF/ FCC/ Anatel/ NCC/ RCMOthers:WHQLEC25-AUX Mini PCIeLTE-FDD: B1/B2①/B3/B4/B5/B7/B8/B28LTE-TDD: B40WCDMA: B1/B2/B5/B8/B4GSM/EDGE: Quad-bandEmbedded GNSS: OptionalRegion:Latin America/Australia/New ZealandRegulatory:CE/ NCC/ Anatel/ RCMOthers:WHQLNotes:① LTE-FDD B2 of EC25-AU Mini PCIe and EC25-AUX Mini PCIe does not support Rx-diversity.* Under developmentWhy Choose UsFAQQ1. What is the minimum order quantity for your products?A1. Minimum order quantity starts from ONE piece.Q2. What's the quality of your products?A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products.Q3. Is this product free of shipping or free samples?A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.All Categories4G 5G ModuleGPS ReceiverGPS AntennaGSM/LTE/WiFi AntennaGSM/LTE+GPS AntennaGNSS/GPS Module2G/3G/4G ModemGPS TrackerRF Coaxial / ConnectorSIMCard HolderSensorIC
>>
