High Quality Fuwa Lifting Equipment 70 Ton Hydraulic Tracked Crawler Crane Xgc70

Product Description

High Quality Fuwa Lifting Equipment 70 Ton Hydraulic Tracked Crawler Crane XGC70
The hydraulic components are imported from Rexroth, and the performance is more superiority
Extendable track frame, compact outline, small swing radius, making it convenient to transport
The main, aux. Winch is equipped with free fall function, saves fuel consumption, and boosts work efficiency.
The main, aux. Winch and derricking is equipped with mechanical brake, and better safety performance
The The easily damaged and consumable structural parts are self-made, . And special structure design of FuWa, makes maintenance more convenient.
Most part of whole crane surface adopts no-dust baked lacquer automatic assemble line painting.

Item				Unit
Main boom				m	12~54
Jib length				m	9~18
				m	45+18
				º	30~80
Working speed	Wire speed	Lifting (4th floor)		m/min	80/40 130/65(lifitng)
		Dropping (4th floor)		m/min	80/40 130/65(lifitng)
		Lifting arm lifting		m/min	58
		Lifting arm dropping		m/min	58
	Steering speed			r/min	3.7
	Travelling speed			km/h	1.2
			10 12		20t 14.3t (lifting)
Gradeability				%	30
Engine and rated power				KW/r/min	China Cummins 6CTA8.3-C240 182KW/2000r/min & Imported Cummins QSL-9 209KW/2100 r/min
Machine weight				t	69
Pressure				MPa	0.078
Counterweight				t	24

---
