Plastic Film Slitter Rewinder (QFJZ-700, 1100, 1300,1600)

Product Description

Kingsun have more than fiftyy different type of slitter rewinders, and we constantly developing new model for special purpose. With more than 15 years in this particular line, our thousands of slitters are successfully running in the world. This kinds of machinery are widely used in many area for slitting and rewinding plastic film, Al foil, paper and other special
Materials.
Main Features:
1)This machine is vertical type, it is efficient and save space.
2)Independent master control system makes its more flexible and easy to operation.
3)The unwinding unit adopts automatic Position Line(Edge) Controller, the photocell can trace transparent materials and colour line.
4)The unwinding unit adopts magnetic powder brake to control the tension.
5)The rewinding unit adopts magnetic powder clutch to control the tension.
6)Waste film blowing pipe or rolling device can be choose by buyer.
7) Automatic meter counter
8)air shaft for rewinding roller
Main data:
Max unwinding diameter: 600mm
Max rewinding diameter: 450mm
Slitting width: 30mm-600, 1000, 1300mm
Slitting speed: 5-160m/min
Deviation error: Less than 0.5mm
Machine power: 2.2kw, 3kw

---
