Fully Automutic Honeycomb Paper Cutting Machine for Paper Wrap Honeycomb Paper Wrapper

US$32,500.00 1 Set (MOQ)

Basic Info.

Model NO.
SD-PH600
Species
Rotary Die-Cutting Machine
Imprinting Type
Rotary
Placing Form of Template
Horizontal
Die Cutting Tool
Steel Blade
Computerized
Computerized
Automatic Grade
Automatic
Application
Paper Packaging Materials, Dust-proof Material, Retail
Voltage
1/2/3 Phase, 220V/380V, 50/60 Hz
Power
5
Weight
2500kgs
Certification
CE
Max.Width of Material
535mm
Max.Diameter of Roll
1200mm
Transport Package
Wooden Box
Specification
2300*1350*1300mm
Trademark
SNDA, OEM
Origin
Wenzhou, China
HS Code
8441100000
Production Capacity
30 Sets Per Month

Product Description

Performance And Characteristics
Machine features This machine is suitable for die cutting honeycomb paper,wrapping paper, shock-absorbing paper, kraft paper,fish net paper from 50g to 100g. The unwinding,cutting and rewinding in one process. Main motor equipped with Inverter for speed regulation. Computer with PLC and servo motor controlled, touch screen Main machine body with thicker iron plate Tension controlled automatically by magnetic powder brake and clutch Automatic meter counting device,automatically stop after it reaches the length you set. Automatic finished roll changer inline(finished paper roll without shaft inside) Automatic lifting system in unwinding with web guiding system
Model SD-PH600
Max.width of mother roll 535mm
Max.diameter of mother roll 1200mm
Max.diameter of finished roll 300mm
Paper Core diameter(Rewind and unwind) 1"/1.5"/2"/3" in rewinder and 3inch(76mm) in unwinder
Cutting Speed 0-200m/min adjustable
Total power 5kw
Gross weight 2500 KG
Overall dimensions 4800*1500*1800mm
Machine Delivery
