| US$7,400.00-8,400.00 | 1 Set (MOQ) |
| Specification | Unit | X6332Z |
| Spindle taper | ISO40(V,H) | |
| Distance from spindle nose to table | mm | 90-490 |
| Disance from spindle to column | mm | 200-550 |
| Spindle speed range | r/min | 90-2000(V) 40-1300(H) |
| Spindle travel | mm | 120 |
| Max. Drilling dia. | mm | M14 |
| Head movement | deg | ±45 |
| Table size | mm | 1370*320 |
| Table travel X/Y/Z | mm | 720/300/400 |
| Max.weight of workpiece | kg | 360 |
| Feeding range of longitudinal, cross travel | mm/min | 22-555 |
| Auto-feeding of Z-axis | mm/min | 560 |
| T-slot number/width/distance | 3/14mm/70mm | |
| Horse power for main motor | kW | 0.85/1.5(V) 2.2(H) |
| X axis driving motor | W | 370 |
| Overall dimensions | mm | 1700*1500*2270mm |
| N.W/G.W | KGS | 1700/1880KGS |
| Hercules Machinery Equipment Ltd. | ||
