Cow Dung Manure Solid Liquid Separator Dehydrator Dewatering Machine

Product Description

Poultry dung manure solid liquid separator extruder machine
This Cattle Farming Equipment is a solids-liquid separating machine including a screw conveyor. Using both principles of separation, by gravity and by mechanical pressing, the machine is designed to separate the liquid phase from the solid phase in a wide range of substances such as sludge, sewage, manure, solids-liquid mixtures, vegetables, processing waste and others, where the percentage of liquid inside the solid may be considerably different. The separated solid and liquid phases can be handled in an easier and cheaper way. In some sectors this can even become a source of income.
Part one:
1. It widely used to reduce the water content of sawdust, animal dung, acid-sludge, medicine dregs, kitchen rubbish, and many other dregs.2. If the raw material is solid, when its moisture more than 60-90%, the machine could lower the moisture to around 50%.3. If the raw material is liquid, the solid content in the raw material can be 30-40%, and the moisture of final product is about 40-50%, you can't press out any water by hands. After processing with this machine, the final product could be used as raw material of organic fertilizer or biomass briquette.

No.	Model nr.	Voltage(V)	Motor power(KW)	Conveyer pump power (KW)
WSFB-1	HM-140-3	380	3	3
WSFB-2	HM-180-4	380	4	3
WSFB-3	HM-400-11	380	11	6

Part two: Operation of dung dewatering machine
The machine receives the material to be separated and conveys it using the screw conveyor inside the
separator casing. The liquid phase is separated through the mesh of the cylindrical screen which encloses thescrew conveyor. Along its path toward the exit, the material gradually separates progressively the less linked
liquid and then the more strongly linked liquid until a plug of almost dry material has formed before the outlet. The plug is continuously expelled through the outlet diaphragm.The machine will automatically find its balance of squeezing force depending on the material. Consequently, it can be used for a wide range of materials withoutthe need for any manual adjustments.

Part three: Advantages of dung dewatering machine
1. Compliant with a wide range of materials in different throughput rates.
2. Optimized feeding thanks to compensator tank.
3. Outlet diaphragm for solids manufactured from anti-wear engineering polymer: cost saving in spare parts.
4. Self-balanced pressure at the solids outlet: steady and safe operation.
5. Simple operation and cost saving in spare parts.
6. Low power consumption.
7. Continuous operation.

8. Quick return on investment.
Remarks:
I.Delivery time: 15 days after receiving clients' prepayment.
II.Payment term: 50% as prepayment by T/T, the balance of 50% should be paid after the scan document of B\L.
III. Valid time: This quotation is valid for one month.
IV .Quality Guarantee Terms:
Quality guarantee term is for one year. Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self.

---
