economic Single Shaft Shredder for Recycling

Product Description

Characteristic:
A)The project is designed for special equipment in Thailand timber designed to root slices, for the characteristics of rubber tree roots, roots with a large diameter WT Series slicer, so that large-diameter, irregular roots do not need to cut wood can be formed directly by cutting, to meet different production needs. Grasping machine loading, continuous feed, continuous cutting, wood products sent by the belt conveyor. Large-scale production of wood chips for boiler fuel or wood-based panels do (MDF / BP) plant as raw material.
B)This set of equipment without special foundation, according to the need to determine placement.
C)This set of equipment investment cost low, operation costs low.Size and performance parameters:

Model	HW40120	HW40150	HW48200	HW48250
A(mm)	2825	2825	3155	3243
B(mm)	2564	3080	3850	4913
C(mm)	1410	1410	1560	2258
D(mm)	1200	1500	2000	2500
E(mm)	500	500	600	600
H(mm)	1875	2200	2105	3220
Cylinder stroke(mm)	900	900	1000	1000
Rotor diameter(mm)	φ400	φ400	φ480	φ480
Spindle speed(r/min)	110	110	110	120
Mesh aperture(mm)	φ40	φ40	φ40	φ40
Number of Flying(PCS)	70	88	118	220
Fixed knife(PCS)	2	3	4	5
Main motor power(KW)	55	75	75+75	132+132
Oil pump motor power(KW)	2.2	5.5	7.5	7.5
Capacity	4-5t/h	6-8t/h	10-12t/h	18-20t/h
Weight(KG)	5000	6200	10000	13000

---
