Electronic One Stop PCBA Manufacturer PCB Assembly

Product Description

WELCOME TO XJYPCB------------------
Shenzhen Xinjiaye Electronics Technology Co., Ltd is a professional pcb manufacturer has over 10 years experience. We are able to offer 1 to 24 Layer PCB, ranging from pcb produce, components purchase, pcb assembly, pcb copy service.Our products are widely used in communication apparatus, automobile electronics, auto parts, computers, medical devices, light systems, outdoor systems, network devices and consumer electronics class fields.
+++++++++
Quick Details

Place of Origin:	Guangdong China (Mainland)	Brand Name:	XJY	Model Number:	xjy-pcb 206
Number of Layers:	Multi-layer	Base Material:	FR-4	Copper Thickness:	35um
Board Thickness:	1.6mm	Min. Hole Size:	0.25mm	Min. Line Width:	0.2mm
Min. Line Spacing:	0.2mm	Surface Finishing:	Immersion gold plating	Soldermask:	Green Black Red or custom color

Certification: UL, RoHS, ISO9001: 2000
Board Thickness: 0.2MM-2.4MM
Min. Hole Size: 0.2MM
Min. Line Width: 0.15MM
Min. Line Spacing: 0.2MM
Surface Finishing: LF-HAL
Solder Mask Type: Blue
Silkscreen: White
UL, IOS9001, RoHS
Quick lead time 24hours for 2-4layer PCB
++++++
Technology capability

Items		Single/Double-sided Board/Multilayer Board/FPC(1-24Layer)
Base Materials		FR-4(High TG 150°-170°),FR1,Aluminum,CEM-3,BT,94vo
Finish copper thickness		Outer 6 OZ,Inner 4 OZ
Surface finish		ENIG, ImAg, ImSn, OSP, HASL,Plating gold
Finished Board Size		Max Double-sided Board	640mm χ 1100mm
		Max Multilayer Board	640mm χ 1100mm
Finished Board Hole Size (PTH Hole)		Min Finished Board Hole Size	0.15mm
Conductor Width and Spacing		Min Conductor Width	0.01mm
		Min Conductor Spacing	0.01mm
Thickness of Plating and Coating Layer		PTH Wall Copper Thickness	>0.02mm
		Tin Solder Thickness ( Hot Air Leveling )	>0.02mm
		Nickl/Gold Thickness	For customer special need
		Nickl Plating Layer	>2um
		Gold Plating Layer	>0.3um
Bare Board Test	Single Side Test	Max Test Point	20480
		Max Board Test Size	400mm χ 300mm
	Double Side Test	Max Test Point	40960(General Use)
			4096(Special Use)
		Max Board Test Size	406mm χ 325mm
			320mm χ 400mm
		Min Test pitch of SMT	0.5mm
		Test Voltage	10-250V
Mechanical Process		Chamfer	20°, 30°, 45°, 60°
		Angle Tolerance	± 5°
		Deepness Tolerance	± 0.20mm
		V-Cut Angle	20°, 30°, 45°
		Board Thickness	0.1-3.2mm
		Residues Thickness	± 0.025mm
		Cell Paraposition Precision	± 0.025mm
Tolerance of Out-shape Process			± 0.1mm
Board Warp		Max Value	0.7%
Optical Plotting		Max Plotting Area	66mm χ 558.8mm
		Precision	± 0.01mm
		Repetitive Precision	± 0.005mm

Testing Procedures For PCB Board
---We perform multiple quality assuring procedures before shipping out any PCB board. These include:
* Visual Inspection
* Flying probe
* Bed of nails
· * Impedance control
· * Solder-ability detection
* Digital metallograghic microscope
· *AOI (Automated Optical Inspection)
Detailed Terms for PCB Manufacturing
---Technical requirement for PCB assembly:
* Professional Surface-mounting and Through-hole soldering Technology
* Various sizes like 1206, 0805, 0603 components SMT technology
* ICT(In Circuit Test), FCT(Functional Circuit Test) technology.
* PCB Assembly With UL, CE, FCC, RoHS Approval
* Nitrogen gas reflow soldering technology for SMT.
* High Standard SMT&Solder Assembly Line
* High density interconnected board placement technology capacity.
Delivery Time for PCB board
1) PCB production time: Sample: 3-4 days / mass production: Within 7 days
2) Component purchase: 2 days if all components is available in our domestic market.
3) PCB Assembly: Samples: Whthin 2 days / mass production: Within 5 days
Quotation Requirement and Time:
1) Following specifications are needed for quotation:
A) Base material:
B) Board thickness:
C) Copper thickness:
D) Surface treatment:
E) color of solder mask and silkscreen:
F) Quantity
2) Qutoation within 2 hour after we get the gerber file or PCB file with complete specifications
Shipping Method and Payment terms:
1. By DHL, UPS, FedEx, TNT using clients account.
2. We suggest you using our DHL, UPS, FedEx, TNT forwarder.
3. By EMS (Usually for Russia Clients), price is high.
4. By sea for mass quantity according to customer's requirement.
5. By customer's Forwarder
6. By Paypal, T/T, West Union, etc.
