Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
This section provides the procedure to connect fiber‐optic cables from the 100BASE‐FX, MT‐RJ fixed front panel ports of the A4H124‐24TX or A4H254‐8F8T to the network or other devices. Each fiber‐optic link consists of two fiber‐optic strands within the cable: Transmit (TX) and Receive (RX). The transmit strand from an A4H124‐24FX or A4H254‐8F8T fixed MT‐RJ port connects to the receive port of a fiber‐optic 100BASE‐FX Ethernet device at the other end of the segment. The receive strand of the applicable MT‐RJ port on the switch connects to the transmit port of the fiber‐optic 100BASE‐FX Ethernet device. To connect a fiber‐optic cable segment to the switch, refer to Figure 2‐17 on page 2‐26 and proceed as follows: 1. Remove the protective covers (not shown) from the MT‐RJ front panel connector and from the connector on each end of the cable. 2. Insert the MT‐RJ cable connector into the MT‐RJ front panel port until it clicks into place. 3. Verify that a link exists by checking that the Link/Activity LED is ON (solid green or blinking green). If the Link/Activity LED is OFF, perform the following steps until it is on: a. If there are separate fiber‐optic connections on the other device, check the crossover of the cables. Swap the cable connections if necessary. b. Verify that the fiber connection meets the dB loss and cable specifications for multimode cabling. 4. If a link is not established, contact Enterasys Networks. Refer to “Getting Help” on page xvii for details. Repeat all steps above until all connections have been made. Note: An odd number of crossovers (preferably one) must be maintained between devices so that the transmit port is connected to the receive port of the other device and vice versa. Note: Leave the protective covers in place when the connectors are not in use to prevent contamination. Caution: Do not touch the ends of the fiber-optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants. Contamination of cable ends causes problems in data transmissions. If the ends of the fiber-optic strands become contaminated, use a canned duster to blow the surfaces clean. A cleaning swab saturated with optical-grade isopropyl alcohol may also be used to clean the ends. Precaución: No toque los extremos de los cables de fibra óptica y evite su contacto con el polvo, la suciedad o con cualquier otro contaminante. Si los extremos de los cables se ensucian, es posible que la transmisión de datos se vea afectada. Si nota que los extremos de los cables de fibra óptica se ensucian, utilice aire comprimido para lim
>>
