Product Description
Product Description
Features
1.full-automatic bending .
2.material thickness capability from 3 mm to 25 mm. suitable for all types of thermo plastic sheet (PP-R, PP-H, PP-B, PP-S, HD-PE, PVC-U, PVC-RL, PVDF…).
3.digital travel distance measurement and control including motorised material transport.
4.by separating the bending function from the heating/transport function, the physical bending of the first leg is performed while the second bend is being heated up.
5.performs up to four bends fully-automated; no human intervention is necessary.
6.user friendly concept of operation with 10" touch-screen.
Range of Application
Manufacturing water tanks and containers, plastic devices, ventilation systems, water treatment systems,Scrubber, environmental technology, swimming pool, transportation and logistics.
Technical Data
| Model | S-ZW3000B |
| Machine Length (mm) | 4300 |
| Machine Width (mm) | 2000 |
| Machine Height (mm) | 1500 |
| Total Weight approx. (kg) | 3000 |
| Maximum Working length (mm) | 3050 |
| Bending Thickness (mm) | 3-25 |
| Bending Angle | 0-95° |
| Minimum channel cross-section of bending | 155 x 155 |
| Power supply standard | 220V/380V 50/60Hz |
| Power consumption (kVA) | 12.5 |
| Compressed Air Connection | 6-8bar |
| Upper Heating Element | 3200X30X50m，82° |
| Lower Heating Element | 3200X28X45mm，flat |
>>
