M1412X350 small Universal Cylindrical Grinding polishing Machine

Product Description

Product Feature:
The grinder is designed for grinding the external diameter ,external conical face ,internal bores, internal conical face and shoulder of medium-small sized shaft ,sleeve ,flange and etc.
The worktable ,work head and wheel head are able to be swiveled for adequate angle ,worktable and wheel head can be operated hydraulically or manually, in order to meet the needs of manufacture workshop maintenance workshop or tool workshop;
The grinder can use center ,chuck or spring collect to fix workpiece

Model	M1412x350	M1412x500
Max diameter to be ground X length	125x350mm	125x500mm
Min diameter to be ground	4mm
Range of the bore to be ground	10~40mm
Max .depth of bore to be ground	50mm
Height of center x Distance between centers	100x370mm	100x520mm
Max.weight of workpiece	10kgs
Rotation angele (°) worktable headstock wheel frame	±9 ±45 ±180	±7 ±45 ±180
he largest diameter wheel x Thickness	300x40mm
Power of motors(kw)main motors	2.2kw
Total power of the motors	3.245kw
Net weight (T)	1.6	1.7
Gross weight(T)	1.8	1.9
Dimensions(length x width x highness)	1770×1160×1300mm	2240×1160×1300mm
Package size(length x width x highness)	2000×1500×1900mm	2200×1500×1900mm
Working Accuracy Roundness Cylindricity Roughness	0.0015mm 0.003mm 0.32mm	0.0015mm 0.005mm 0.32mm

HYMT SERVICE:
1.Standardization of Service "212"
2: response in 2 hours
1: provide solution in 1 day
2: solve complaint in 2 days
2.Installation Service
Installation Services are available with all HYMT machines. We dispatch technician to customer's
factory for installation and preoperation of machines.
3.Training Service
Our technician is available to your factory and offer training of how to use our machines. As well, you
may send your technician to our company to learn how to operate machines.
4.Quality Guarantee
We guarantee the quality of machine (e.g. processing speed and working performance is the same as the data of samples making). We sign the agreement with detailed technical data.
We arrange final test before shipment. We run the machine for a few days, and then use customer's materials for test. After making sure machine is the best performance, then make shipments.

---
