Basic Info.
Support System
Android 9.0
Resolution
1920*1080(Full HD)
Projection Technology
3.5 Inch LCD + 58W White LED
Focusing Mode
Manual Focus
Speaker
G55W*2 Subwoofer Surround Sound Speaker
Projection Size
50-200 Inches
Projection Distance
1-6 Meters
CPU
Mtk Decode 4K H265/AVS2 4K*2K/30Hz
Projection Method
Front, Rear, Ceiling Mount
Inputs/Outputs
USB Host 2.0*1, HDMI 2.0, Audio Output,
Package Accessories
Box, Tripod, Power Adapter and IR Remote Control
Specification
205mm*205mm*270mm
Production Capacity
50000PCS/Years
Packaging & Delivery
Package Size
47.00cm * 35.00cm * 42.00cm
Package Gross Weight
15.100kg
Product Description
Product Description
| Item | Product Characteristic | Product parameters |
| OPTICS | Display technology | 3.5 inch LCD |
| Type of light source | 58W White LED |
| Color Brightness | 200 ANSI /5000 Lumens |
| Uniformity | >85% |
| FOFO Contrast Ratio | 10000:1 |
| Standard Resolution | 1920*1080P |
| PROJECTION | Throw Ratio | 1.4:1 |
| Throw Range | 50-200 Inches |
| Throw Distance | 1-6Meter(s) |
| Aspect Ratio | 16:09 |
| Keystone Correction | Automatic, vertical: ± 40 D Manual size keystone |
| Projection Methods | Front Projection,Rear Projection,Hanging cast |
| Zoom | available |
| Texture of material | Plastic ABS+ electroplating + metal |
| Focus mode | Electric motor focusing |
| SYSTEM PARAMETERS | CPU | MTK Decode 4K H265/AVS2 4K*2K/30HZ |
| Clock Speed | 64-bit CPU: Contex A53 4-core GPU: Mali-G31 |
| Memory RAM | 2G DDR3 |
| Flash Storage | 32GB eMMC |
| Operating System | Android 9.0 |
| Bluetooth | BT 5.0 (Support external bluetooth Speaker, mouse) |
| Internal Speaker | 5W*2 Subwoofer Surround Sound Speaker |
| WIFI | Dual 5G | 2.4G |
| Miracast | Airplay,Miracast |
| Remote Control | Infrared remote control and support 2.4g wireless remote control |
| ELECTRICAL SPECIFICATIONS | Total Power Consumption | 58W |
| Battery Capacity | no battery built in |
| Temperuate and Humidity | Working temperature 5°C-40°C, working humidity 20%-80% Storage temperature -10°C-50°C, storage humidity 20%-80% humidity (non-condensing) |
| Power Performance | AC100-240V built-in power board |
| INTERFACE | USB | USB HOST 2.0*1 |
| HDMI | Support HDMI 2.0 input |
| Headphone Output | Audio output, 3.5mm connector (headphones or speakers) |
| OTHER PARAMETERS | Product Size | 190*130*140mm 1.249 kg |
| Package Size | 233*244*157mm 1.72kg |
| Carton Size(8set/box) | 480*510mm*350mm 14.8kg |
| ATTACHMENTS | main projector*1 |
| tripod*1 |
| IR remote control*1 |
| power adapter*1 |
Detailed Photos
Customers Also Bought
Company Profile Youyuan is a one-stop shopping service from development to production, sales and exporting company. Every year, we cooperate with local designer, as well as European designer, for new design models. Basing on stable quality, good service and reasonable price, our goods export to more than 80 countries all over the world.
To improve the quality and to up to the advanced international standards, Youyuan enhances QC, upgrades the machines, learn the advanced technology and fashion design from overseas.
FAQ
1. Do you have certificates?
Yes.We have CE, Rohs, FC, FCC, BSCI, etc.
2. Do you support OEM and ODM service?
Yes.
A. Logo printing
B. Customized package
C. Software customization: Booting image, UI, App, Function, etc.
D. Housing mould, etc.
3. What is the lead time?
For samples: within 1-3 working days for standard products in stock.
For bulk order: about 15-20 working days after we receive the 30% deposit and customers confirm all the packaging details.
4. Can my parcel be tracked and when can I get the tracking number of my parcel?
We will send you the tracking number on the second day after the parcel is shipped. You can track the parcel at the official website of the delivery company.
5. What kind of power adapter can you provide?
EU, UK, US, AU four standards of plugs are available. We will send the different adapter to you according to your country or requirements.
6.What's your warranty?
All products have 3 years warranty. If there is any quality problem(not man-made), we will replace or repair for you freely. Mainwhile our engineers will patiently tell you how to solve it. If there's still a problem with the help of our engineers, you can return us the defective products for maintenance. And then we will send back good items to you ASAP. Customers need to be responsible for the shipping costs. In order to avoid loss, all our goods are tested carefully by technical staffs before delivery, please rest assured!
7.What kinds of products do you supply?
A. Projector
B. Hair Dryer
C. Smart Trash Can
D. Security Camera
E. Bug Zapper
F. USB Fans
Attention: If you want to get a cheaper, faster and safer shipping method, you can click contact suppliers and we will get back to you immediately during working hours. In order to avoid loss, all our goods are tested carefully by technical staffs before delivery, please rest assured!
>>
