Hydraulic System Hot Working Temperature Monitoring Chinese Manufacturer Automated Basic Terminology for Hot Punch Press Machine

Product Description

Product Description

Model		RN190-160C	RN220-200C	RN250-250C	RN250-315C	RN300-400C
Molds Distance	Ton	190	220	250	250	300
Press Power	times/min	160	200	250	315	400
Press Speed	pcs	55	50	40	40	35
Capacity when double press	mm	≤43	≤40	≤30	≤30	≤25
Can produce the hex nut	mm	≤50across flats of nuts(single press≤55)	≤60across flats of nuts(single press≤65)	≤65across flats of nuts(single press≤80)	≤70across flats of nuts(single press≤90)	≤75across flats of nuts(single press≤100)
Package Size L*W*H	mm	1600X1400X110	1900X1450X1100	190X1550X1100	1900X1550X1100	2000X1700X1100
Weight	kg	1600	1800	2500	2800	3500

If you need to produce bigger size parts, please contact with us.
Hot forging machine/ Hot nut former machine produced by Ronen Wuhe is suitable for auto-parts, construction hardware, construction fasteners, bearing producing, machinery, electronics, etc. industrial fields, we have big share in domestic market, and in recent years, we have exported to Europe, USA, Korea, Russia, India, Indonesia, Vietnam etc. countries. At present, the largest model can reach 400T , sizes from M27~M64, fully automatic and non-automatic.
PRODUCT RANGE OF NUT MAKING MACHINE
Our products include standard parts and non-standards, such as:
Flange Nuts, Weld Nuts, Square Nuts, Rivets, Hex nuts, Square Nuts, Sleeves, Acorn Nuts, Barrel Nuts, wing Nuts, Weld Nuts, Split Nuts, Nylon Nuts, lock Nuts.
Production Line Location
Production Line Introduction
1. The raw material is bar steel, and the automatic bar steel cutting machine is used to cut the material. The cut material is flat at both ends. The head and end materials of the bar are automatically separated and enter the waste area. The good materials is conveyed into the storage bin of the fully automatic feeding machine. 2. The automatic feeding machine will push the material into the hearth furnace position of the induction heating machine according to the set frequency, and automatically push it out after heating, without the need for human supervision. 3. The heating equipment adopts induction heating, and the material is pushed into the heating furnace by the automatic feeder, and the frequency is automatically heated according to the heating progress. 4. The heated workblank is also slid into the guide tube of the hot forging CNC synchronous manipulator from the intermediate frequency protection control exit through the slide, and the manipulator clamps the workblank into the mold and heat-acid-formed. 5. Install the control buttons of the shearing machine, intermediate frequency and automatic feeding machine near the operator. One nut hot forging production line only needs one person to operate (one person can take care of the feeder and the CNC).
Case
Manipulator Description
Easy operation : controlled by buttons, adjust the manipulator movement on the
touch screen, no need to remove the jaws when changing the mold; Multiple functions : there is a single punch action, that is, the punch press produces one finished product every 2 times, which is suitable for producing larger products. It can move the manipulator first and then the punch. It can produce products with a height of about 55. With alarm function, some faults can be alarmed and stopped equipment;
Less failures and easy maintenance: the core parts are purchased parts (see the list for details), with long service life and low failure rate. There is a fault prompt function,
the cause of the fault is easy to detect, and the maintenance is convenient.
Application
Company Profile
Nut Making Machine Factory Introduction
Ronen Wuhe is one special manufacture for producing Fasteners Machines in China. Has Taiwan Technology level engineers team, and with strict technical monitoring and production process, the plant area is 15000 square meters+.
In addition, in the future, Ronen Wuhe also plans to gradually move in the direction of mold design, Tapping Machine design and
technical consulting. "Manufacturing is like a service industry. After all, who can provide diversified services will have orders
and market leadership."




Workshop Show
Our Services
1. Aliwangwang, Email, Whatsapp, Wechat, Facebook etc. 24 online.
2. After getting your inquiry, we would like to reply to you within 24 hours.
3. Please confirm us the nuts sizes or nuts drawing in the inquiry, so that we could check out the suitable machine.
4. After confirming our quotation & proposal, we would like to sign contract with you.
5. Delivery the order to clients with rich experience.
6. Machine operation & maintenance training at buyer or at seller is available.
7. Commissioning and installation at the clients work site. 8. Free spare parts for after-sales service
FAQ

-Are you a manufacturer or trading company?
We are a manufacture and we have more than 20 years experience in producing nut former.
-What about your price?
Our price is the standard price, based on the product drawing or size.

-How about the shipping?
It depends on your choice, and we have the shipping partners of many years of experience. And we have rich experience in customs clearance. We have exported to Europe, USA, Korea, Russia, India, Indonesia, Vietnam etc.

-How about the package?
Anti-rust plastic film

-Do you offer after-sale service?
Yes, we provide lifetime warranty of the machine.

---
