600W Constant Voltage Constant Current Small Size Power Supply 12V 50A Adjustable Voltage

Product Description

Origin: Wenzhou, China
Brand Name: FUNELEC
Model: S- 600 - 12V
Output power: 600 W
Output type: single group
Input voltage: 110 v / 220 v, 85-264 vac
Output voltage: 12V
Output frequency: 47-63 Hz
Output current: 50A
Size: 215*115*50mm
Weight: 1KG
Quality assurance: 1 year
Protection: short circuit, overload, over voltage, over temperature
Efficiency: >85%
Working temperature: -10 ~ 60ºC
Safety certificate: CE ROSH CCC

600W Switching power supply
DC output voltage	12V	24V	36V	48V	60V	80V	110V
Output voltage tolerance	±1%	±1%	±1%	±1%	±1%	±1%	±1%
Rated output current	50A	25A	16A	12A	10A	7A	5A
Output current range	0-50A	0-25A	0-16A	0-12A	0-10A	0-7A	0-5A
Output current range	120 mVp-p	120 mVp-p	120 mVp-p	120 mVp-p	120 mVp-p	120 mVp-p	120 mVp-p
Incoming line stability	±1%	±1%	±1%	±1%	±1%	±1%	±1%
Load stability	±1%	±1%	±1%	±1%	±1%	±1%	±1%
DC output power	600W	600W	600W	600W	600W	600W	600W
Efficiency	85%	85%	85%	85%	85%	85%	85%
DC voltage adjustable range	0-12V	0-24V	0-36V	0-48V	0-60V	0-80V	0-110V
Input voltage range	190-240VAC/47~63HZ
Input current	5A/230V
Impulse current	46A/230V
Leakage current	<3.5MA/240VAC
Overload protection	120%~150%, type: cut off the output, reset: automatic recovery
Overvoltage protection	120%-150%
High temperature protection	ERH3≥65ºC 70ºC fan start, ≤55ºC~60ºC fan close, ≥80ºC~85ºC, cut off output (5~15V)~(24~48V)
Temperature coefficient	±0.03%/ºC(0-50ºC)
Start, rise, hold time	1S,100MS,50MS
Vibration resistance	10~500HZ, 2G 10min,/1 cycle, duration 60 minutes, each axis
Pressure resistance	Between input and output: 1.5KVAC Input and shell: 1.5KVAC Output and shell: 0.5KVAC
Isolation resistance	between input and output; input and shell, output and shell; 500VDC/100MΩ
Working temperature and humidity	-10ºC~+60ºC (refer to output characteristic diagram), 20%~90%RH
Storage temperature and humidity	-20ºC~+85ºC,10%~95%RH
Dimensions	215*115*50mm
Weight	1KG
Safety standards	GB4949UL60950,EN60950
EMC standard	According to GB9254 EN55022 EN55024 Class A design

FUNELEC focuses on providing LED switching power supplies, waterproof switching power supplies, rainproof switching power supplies and AC and DC power adapters. With overload protection, overvoltage protection and high temperature protection. FUNELEC has won the favor of customers for its high efficiency, reliability and long life. Each switching power supply is very safe and stable after 5 tests. All our forces have CE, ROHS ,CCC certification. Our switching power supplies are widely used in the field of industrial automation, indoor and outdoor LED lighting, and LED lighting projects.

---
