Maximum Capacity | 12000lb (5443kg) |
| Voltage | 12 Volts DC |
| Gear Ratio | 295.75:1 |
| Gear Train | 3 Stage Planetary |
| Clutch | Sliding Ring Gear |
| Motor Type | Series Wound |
| Motor | 6.5hp, 4.8kW |
| Control | Hand Control, 3m Lead |
| Braking | Automatic Load Holding In Drum |
| Drum Size | 67mm x 228mm |
| Synthetic rope in grey | 26m x 9.5mm |
| Clevis Hook | 3/8" |
| Overall Dimensions | 570mm x 168mm x 175mm |
| Net Weight | 43kg |
| Mounting Bolt Pattern | 254mm x 114.3mm |
| Battery Power Cables | 2 x 25mm², Tinned Copper with Sheath Protection |
| Motor Power Cables | 3 x 25mm², Tinned Copper with Sheath Protection |
| Recommended Battery | Minimum 650CCA |
| Finish | Powder-coated |
Line Pull | Line Speed | Motor Amp |
| 0lbs (0kg) | 14 Fpm (4.2 Mpm) | 90A |
| 4000lbs (1816kg) | 9.2 Fpm (2.8 Mpm) | 190A |
| 6000lbs (2724kg) | 7.9 Fpm (2.4 Mpm) | 230A |
| 8000lbs (3632kg) | 6.9 Fpm (2.1 Mpm) | 260A |
| 1000lbs (4540kg) | 6.5 Fpm (2.0 Mpm) | 300A |
| 12000lbs (5443kg) | 5.9 Fpm (1.8 Mpm) | 330A |
Cable Layer | Rated Line Pull | Cable Capacity |
| 1 | 12000lbs (5443kg) | 15 Feet (5m) |
| 2 | 10200lbs (4631kg) | 38 Feet (11.5m) |
| 3 | 8400lbs (3814kg) | 64 Feet (19.5m) |
| 4 | 7300lbs (3314kg) | 95 Feet (29m) |
| 5 | 6500lbs (2950kg) | 100 Feet (30.5m) |
