| Model | DG11000LED |
| Frequency[Hz] | 50 60 |
| Voltageg[V] | 220.230.240.110/220.115/230.120/240.230/380.230/400.240/415 |
| Rated Power( KW) | Single phase 6.5/Three phase 7.3 Single phase7.0/Three phasea 7.8 |
| Max. Power(KW) | Single phase 7.0/Three phase 7.8 Single phase 7.5/Three phase 8.3 |
| Rated Output Current（A ) | Single phase 21.6/Three phase 10.5 Single phase 23.3/Three phase 11.2 |
| DC Output | 12V 8.3A |
| Phase | Single phase/Three phase |
| Excitation Method | Brush self-excitation |
| Power FactorΦ | 1.0(0.8) |
| Insulation Class | F |
| Fuel Tank Capaciity[L] | 12.5 |
| Engine Model | 1100FE |
| Start Method | Electric Start |
| Engine Type | Single cylinder,4-stroke,air-cooled, vertical |
| Bore*Strokke[mm] | 1-100*85 |
| Displacement | 0.667L |
| Compression Ratio | 19.5：1 |
| Speed[rpm] | 3000 3600 |
| Power [Kw] | 10 10.5 |
| Oil Capacity[L] | 2 |
| Fuel Consumption[g/kwh] | ≤285 ≤295 |
| Fuel No. | Diesel: 0#(Sumner), -10#(Winter) Use No. 0 diesel in summer, and use No. -10 or No. -20 diesel in winter. |
| Oil No. | SAE10W30 (CD grade or above) uses CD or above grade 15W-40 oil (or SAE equivalent grade oil) |
| Optional | ATS,Remote Control,Intelligent digital display panel |
| Size [mm] (L*W*H) | 780*585*705 |
| Packing Size [mm] (L*W*H) | 800*605*725 |
| Net Weight/Gross Weight[Kg] | 132/136 |
