| MODELS | C0632D | C0636D |
| Swing over bed | 330mm(13 ") | 360mm(14 ") |
| Swing over cross slide | 198mm(7-25/32 ") | 224mm(8-13/16 " | |
| Swing in gap diameter | 476mm(18-3/4 ") | 502mm(19-3/4 ") |
| length in gap | 210mm(8-1/4 ") | |
| Center height | 166mm(6-1/2 ") | 179mm(7 ") |
| Admits between | 1000mm(40 " ) | |
| Spindle bore | 38mm(1-1/2 " ) or40mm(1-9/16 ") | |
| Spindle nose | D1-4 orD1-5 | |
| Taper in nose | No5 morse | |
| Speeds number | 8 | |
| Speeds range | 70-2000r/min | |
| Cross slide travel | 170mm(6-11/16 ") | |
| Compound rest travel | 95mm(3-9/16 ") | |
| Lead screw thread | 8T.P.I. or 3mm pitch | |
| Feed rod diameter | 19mm(3/4 ") | |
| Cutting tool max section | 16mmxl6mm(5/8 " x5/8 ") | |
| Threads imperial pitches | 42 Nos. 4-112T.P.I | |
| Threads metric pitches | 44 Nos. 0.1-7mm | |
| Threads diametral pitches | 25 Nos. 16-112DP | |
| Threads module pitches | 34 Nos. 0.1-1.75MP | |
| Longitudinal feeds imperial | 24 Nos. 0.00168-0.1175 " /rev | |
| Longitudinal feeds metric | 24 Nos. 0.046-3.249 mm/rev | |
| Cross feeds imperial | 32 Nos. 0.00046-0.03231 11 /rev | |
| Cross feeds metric | 24 Nos. 0.01-0.703 mm/rev | |
| Quill diameter | 32mm(1-1/4 " ) or 42mm(1-21/32 ") | |
| Quill travel | 100mm(3-15/16 11) | |
| Quill taper | No3 morse | |
| Main motor power | 1.5kW(2HP) | |
| Coolant pump power | 40W (1/16HP) | |
| Packing size | 93cm x 76cm x 153cm | |
| NG/GW | 540/645 kg | |
