High Speed Machine Hj/420ba

Product Description

H Series /Precision High -Speed IMM
Sepcial design, Super speed
Clamping unit, High rigidity
Ultra-thin product, High Q&E
Injection &charging , High precision
Close-loop servo, Unique leading
Oil bushings, Stable Durable
H series main features: Clamping structure / unit as well as machine body is with high rigidity &high load capacity design , which can ensure machine's stability and durability Suitable hydraulic system design matches with high response controller , which guarantees the machine with shorter cycle time and achieve high speed / precision function requirement We have adopted oil self-lubricating bushings and good quality steel rod as well as long lifespan design and manufacture of clamping pins for the machine Coaxial and high agility single cylinder fast injection structure has greatly improved the plastics melting capacity & plasticizing performance The machine is suitable for the processing of thin-wall packing and long flow path products , so as to make sure the production efficiency accordingly

INTERNATIONAL CLASS NO.	420/980
SPECIFICATION	HJ/420BA
screw type	A	B
injection unit
screw diameter	60	65
screw L/D ratio	27	24.9
shot volume (theoretical)	700	822
injection weight(ps)	637	748
injection speed	450	450
injection rate	1160	1361
injection pressure	153	130
screw speed	0-350
clamping unit
clamping force	4200
open stroke	640
space between tie-bars(w*h)	690*670
max.mould height	670
min.mould height	250
ejector stroke	100
ejector force	70
others
pump max. pressure	19/16
pump motor power (servo)	51+51
heating power	27
numbers of heating area	3+1
machine dimension(l*w*h)	8*1.95*2.45
oiltank cubage	850
machine weight	18.5
