| US$130,000.00-150,000.00 | 1 set (MOQ) |
| Technical Parameters | |||
| Preform system | Unit | STIBM95S | |
| Screw diameter | mm | 65 | |
| Screw L/D | L/D | 23:1 | |
| Shot volume | cm3 | 660 | |
| Injection weight(HDPE) | g | 625 | |
| Max.Screw speed | rpm | 10-235 | |
| Heating capacity | KW | 12.6 | |
| No.of heating zone | Qty | 3+N | |
| Clamping system | |||
| Clamping force of preform | KN | 1008 | |
| Clamping force of blowing | KN | 221 | |
| Opening stroke of mold planten | mm | 160 | |
| Lifting H of rotary table | mm | 80 | |
| Max.Platen size(L×W) | mm | 900×480 | |
| Min.mold thickness(H) | mm | 280 | |
| Heating capacity of mould | KW | 8 | |
| Stripping system | |||
| Stripping stroke | mm | 260 | |
| Dry cycle | sec | 3 | |
| Driving system | |||
| Motor power | KW | 26+26+3 | |
| Hydraulic pressure | Mpa | 14 | |
| Product range | |||
| Suitable bottle range | ml | 5-800 | |
| MAX.bottle height | mm | ≤220 | |
| Max.Dia.of bottle | mm | ≤100 | |
| Other | |||
| Min.air pressure | Mpa | 1 | |
| Discharge rate of compressed air | m3/mm | ≥1 | |
| Water flowage | m3/h | 6 | |
() | Total rated power with mold heating | KW | 75.6 |
| Dimension(L×W×H) | M | 5.0×2.0×2.6 | |
| Net weinght | ton | 12 | |
| Name | Brand | |
| 1 | Electro-Hydraulic system | ++ INOVANCE controller+motor+SUMITOMO pump :++Or TECHMATION controller+PHASE motor+ECKERLE pump |
| 2 | Hydraulic motor | INTERMOT OR STF |
| 3 | Hydraulic valve | YUKEN |
| 4 | Seal Kit | COG,DINGZING,HALLITE |
| 5 | Accumulator | OLAER |
| 6 | Oil cooler | DELTA |
| 7 | High-pressure hose | EATON orCONTITEC orPARKER |
| 8 | Air Valve | SMCFESTO |
| 9 | Pneumatic connector | CAMOZZI |
| 10 | Control system | PLC+ OMRON+MCSG |
| 11 | A.C. Contactor | SCHEIDER |
| 12 | Relay | , OMRON or SCHEIDER |
| 13 | Promixity switch | OMRON |
| 14 | Linear Scale | GERFAN |
