| Negotiable | 1 Piece (MOQ) |
| Specification Model | CA6180 | CA6280 | ||
| Max. Swing over bed | 800mm | |||
| Max. swing over carriage | 540mm | |||
| Max.swing in gap | -------- | 1020mm | ||
| Effective gap length | -------- | 210mm | ||
| Max.length of workpiece | 750mm/1000mm/1500mm/2000mm/3000mm | |||
| Width of bed | 400mm | |||
| Section of turning tool | 25 x 25 | |||
| Motor Power | 7.5kw(10HP) | |||
| Spindle | Spindle speed | 10-1400rpm/16-1400rpm(24 steps) | ||
| Hole through spindle | 52mm.(80mm).(105mm) | |||
| Spindle taper | NO.6(MT6)( Φ90 1:20){ Φ113 1:20} | |||
| Feed | Number of feeds | 64kinds for each | ||
| Range of metric threads(kinds) | (1-192mm) 44kinds | |||
| Range of inch threads(kinds) | (2-24tpi)21kinds | |||
| Range of module threads(kinds) | 0.25-48( Module 39 kinds) | |||
| Range of pitch threads(kinds) | 1-96DP(37 kinds) | |||
| Tailstock | Max. Tailstock travel | 150mm | ||
| Tailstock spindle diameter | 75mm | |||
| Taper of Tailstock | NO.5 (MT5) | |||
| Packing Size | 750mm/1000mm/1500mm/2000mm/3000mm | 2550/2700/3200/3700/4850/x 1140 x 1750mm | ||
| weight | Length | G.W KGS | N.W.KGS | |
| 750mm | 2520 | 2400 | ||
| 1000mm | 2720 | 2560 | ||
| 1500mm | 2980 | 2800 | ||
| 2000mm | 3260 | 3087 | ||
| 3000mm | 4200 | 3887 | ||
