Toilet Paper Machinery (1092mm)

Product Description

Toilet Paper Machinery (1092mm)
Product Description
I. Technical parameters:
1. Output paper style: Tissue paper;
2. Raw material: Recycle paper;
3. Output paper weight: 13-40G/M2;
4. Net paper width: 1200mm;
5. Width of cylinder mould: 1450mm;
6. Capacity: 2T/D;
7. Rail gauge: 1880mm;
8. Drive way: AC inverter speed, section drive;
II. Structure of main part:
1. Cylinder section: 1000mm× 1450mm stainless steel cylinder mould 1set, 380mm× 1450mm couch roll 1set,
Coated by rubber, rubber hardness HSD 38± 2.
2. Dryer section: 2000mm× 1450mm alloy dryer can 1set, 350mm× 1450mm touch roll 1 set, coated by rubber,
Rubber hardness HSD 90± 2, dryer can is equipped with double layer exhaust hood of dryer can, pneumactic loading device.
3. Winding section: 1092mm rewinding & perforating machine and paper cutting machine.
Paper making equipment and pulping process flows
The process flows of toilet paper: Waste paper or wood pulp--high concentration aquapulper--high frequency
Vibrating screen--pulp pump--hydrascreen -- bleacher -- propeller-- pulp pump -- efficient double disc pulp grinder -
- pulp pump-- centrifugal screen -- pulp pump -- slag separator -- 1092 type paper machine -- full-automatic rewinding
Perforating machine -- band saw paper cutter -- sealing machine -- marketing
Main equipment

NO.	Item	qty(set)
1	1092mm paper making Machine	1
2	double layer dryer can Exhausted hood	1
3	700mm axial-flow ventilator	1
4	Model-33 Roots vacuum pump	1
5	Suction box	2
6	1092mm winding machine	1
7	calendar(3 rolls)	1
8	rewind machine	1
9	High consistency hydrapulper	1
10	High frequency vibration screen	1
11	double disc Refiner	1
12	sand remover(6 set)	1group
12	bleacher	1
13	Thruster	4
14	centrifugal screen	1
15	inch pulp pump	3
16	inch pulp pump	3
17	air pump cabinet	1
18	inverter control cabinet	1
19	work table	1
20	2ton boiler(burn coal)	1

Company information
Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines.Our products include paper making machines,pulp making machine,parts and paper converting machines such as kraft paper machines,corrugated paper machines,tissue/toilet paper machines,office paper machines, newspaper machines and so on. Our factory gathers and trains many essential technicians and management system to ensure all products meet the quality of ISO and update constantly!
Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana ,Paraguay, Russia, Syria,Pakistan, Tanzania, and Uzbekistan. Our products and services have won customers' consistent affirmations.

---
