Cultivator (TG-4) , Mini Tiller, Rotovator, Diesel Tiller

Product Description

Product Description
TG-4 cultivator is designed with compact structure and light weight. It is suitable for the field of orchard, greenhouse, garden and other small fields. It features the following advantages:
FEATURES:
1. Complicated gearbox design.
2. 178FS vertical type diesel engine as the power of this model cultivator.
3. It has the differential, it is easy to steer the machine.
4. Multi-function
5. Adjustable handle bar. Product Parameters
DETAILED SPECIFICATIONS:

Model		Unit	TG-4
Overall dimensions	Length	mm	1490~1700
	Width	mm	680~820
	Height	mm	820~1140
Clutch type			Belt pulley tension
Steering clutch type			Automatic change, differential
Net weight		kg	150
Tilling width		mm	470-1100
Tilling depth		mm	100-200
Speed			Forward 4 speeds, reverse 4 speeds
Main drive			V-belt
Tyre			4.00-7
Tyre inflation pressure		kPa	100-120 (in the field) 160-180 (for transportation)
PTO speed		r. p. m	Low speed706, High speed 1350
Speed of rotovator			Clockwise 8 speeds, anticlockwise 4 speeds
Driving typeof rotovator			Centre drive
Max. rotary radiusof rotovator		mm	220
Engine		Model	178FS
Max. output		kW	4
Displacement		cc	296
Engine type			Air Cooled 4 Cycle Single Cylinder vertical type diesel
