Product Details
Product Description
Product Description
Features:
1. The cloth spreading machine adopts imported spraying technology, resulting surface that is electrostatically sprayed surface with good smoothness.The high-temperature spray painting further enhances its aesthetic appeal.
2. By adopting high-quality servo motors,which are precise and durable, the machine can operate stably for a long time, with high efficiency and low maintenance costs.
3. The cloth spreading machine adopts an intelligent touch screen and intelligent operating system, it only requires half an hour of training and is easy to learn and operate.
4. With streamlined shape,it reduces wind resistance, noise and vibration. The operating environment is more environmentally friendly.
5. The automatic cloth laying system uses a roller conveyor belt to lay cloth without tension, resulting in better and smoother cloth pulling effect.
6. With automatic edge alignment and fabric cutting, it’s durable and non deformable.
Technical data:
Product Name
| Automatic cloth pulling machine
|
Conventional product models
| PE-B1202
|
Cloth width
| 1.6m,1.9m,2.1m,optional
|
Voltage
| 220V
|
Power
| 1KW
|
Spreading speed
| 0-100m／min（adjustable）
|
Single pull height
| 26 centimeters
|
Double pull height
| 27 centimeters
|
Fabric Weight
| 80KG（max）
|
Fabric diameter
| 50 centimeters
|
Machine size L * W * H
| 2450*1330*900
| 2750*1330*900
| 2950*1330*950
|
Packing size L * W * H
| 2586*1220*1215
| 2886*1220*1215
| 3086*1220*1215
|
Note: It can be equipped with corresponding systems based on customer requirements, and the spreading height can be customized as well.
|
>>
