Stereo Laboratory 40X 1000X Digital Biological Microscope with LCD Display Screen Top

Product Description

ED display with special connector can be used for biological microscope and stereo microscope,after installing,can observe the slides and objects easily, especially for industrial parts' checking,can reduce the visual fatigue and improve checking efficiency

CCD Technical Date:
Device Dimension	1/3"
Horizontal Resolution	700TVLine
Pixels	976(H)X582(V)
LED Technical Date:
Display Dimension	800X600
Color	16,777,216 color
Highest Mode	1024X768@75Hz
Color System	PAL/NTSC4.43/NTSC3.58/SECAM
Microscope Specification:
Eyepiece	WF10X/18mm (optional:WF16X)
Objective	45mm DIN archromatic objective 4X,10X,40X,100X
Viewing Head	Trinocular head,30° inclined,360° rotatable
Total Magnification	40-1600X
Mechanical Stage	125X125mm,moving range:X-Y:60X40mm
Condenser	ABBE condenser:N.A.1.25,2-30mm iris diaphragm and 32 filter
Focusing adjustment	coaxial coarse and fine focusing adjustable mechanism:14mm
Illumination	built-in adjustable brightness 1W LED

2

ITEMS	CONTENS	QUANTITY
1	Main Body	1SET
2	Eyepiece WF10X, P16X	2PCS APIECE
3	Objective 4X 10X 40X 100X	1PC APIECE
4	Reflecting Mirror	1PC
5	Spare Lamp	1PC
6	Spare Fuse	1PC
7	Cedar Oil	1BOTTLE
8	Operation Instrument	1COPY

6.MAINTENCE:
1.The microscope is the same as other optical instrument. Need to be kept in cool, dry, dustless and acidless place. The instrument should be covered with dust guard after using.
2.Never disassemble the lens because they are corrected stringently. If there is stain on the lens, it can wipe out by alcohol, but you should pay attention not seep it into the inside of objectives so as not dissolve glues. Dust on the lens can be wiped away by clean brush.
3.Coarse and fine focusing equipment and nosepiece are precisely constructed and should not be dismantled without authorization.
4.When not in use, keep the objectives in the objective box and cover the eyepiece tube with eyepiece tube cover.

---
