GS-C25 DIN carbon steel bellow globe valve PN16

Product Description

Product Description
GS-C25 DIN carbon steel bellow globe valve PN16
Product Description
Typically, DIN globe valves are made of cast steel with external threads and yoke (OS&Y) and rising stem. Long-life bellows seal designs are available upon request, significantly improving stem sealing performance and ensuring long service life.
It is a cast full bore valve, with female thread, different types of plugs, especially suitable for adjustment, manufactured according to DIN standard.
Din Globe Valve Application
DIN standard sealing globe valve is suitable for various working conditions of petroleum, chemical, pharmaceutical, fertilizer, electric power and other pipelines. The nominal pressure is PN1.6-40MPa, and the working temperature is -20-350°C, that is, it is used to cut off or connect the pipeline medium.
Main Feature:
1. Bellow is the key part of bellow sealed valves, which is welded to both the valve bonnet and valve stem, with automatic roll welding. The metal bellow can keep the stem part 100% no leakage.
2. Double seal design. Bellow from a metal seal to prevent leakage, and packing can provide seal if the bellow failed.
3. Overlay welded seat can keep reliable sealing under severe conditons.
Product Name：Material
Valve Body：GS-C25, CF8, CF8M
Wedge Disc：Overlay 2Cr13, SS304, SS316
Stem：2Cr13, SS304, SS316
Bellows：SS304, SS16, SS321
Bolts：Carbon steel or stainless steel

---
