Wet Type Lab Scale Pq Disk Granulator for Clay Bauxite

Product Description

Wet Type Lab Scale PQ Disk Granulator for Clay Bauxite
1. Application of disk granulator
Model: ZKL(T) Series, PQ(T)-500 Series
Dia.(mm): 500, 600, 800
Weight(kg): 220, 380, 500
Application: Test and study of large-scale granulating for factories, Research Institutes, Colleagues etc.

2. Description of disk granulator All kinds of Granulators are designed by us according to different characteristics in order to adapt to new-product developing and the test and study of large-scale granulating for Manufacturing Factories, Research Institutes, and Colleagues, which could also meet the requirement of all users.

ZKL(T) series granulator Testing Machine is the ZKL series granulators dedicated accessory products. This series granulators testing machine is mainly composed of ball plate, gear, angle adjustment device, rack, frame and other components, who almost has the same working principle with CQP series granulator. When running, the angle and speed of disk could be adjusted for much bigger scale for testing of different material, which can adapt to different test materials and more quickly decide appropriate parameters for the test material into the desired pellet.

The Testing Disk Granulator of PQ(T)-500 is specially matched with Disk Granulator, which mainly consists of Disk Granulator, Drive System, Angle-adjusting System, Engine Base, Electrical System, and etc. When running, the angle and speed of disk could be adjusted for much bigger scale for testing of different material.

3. Main features of disk granulator 1. Adapt to new-product developing and the test and study of large-scale granulating for Manufacturing Factories, Research Institutes, and Colleagues, which could also meet the requirement of all users.

2. Adapt to different test materials and more quickly decide appropriate parameters for the test material into the desired pellet.

4. Export country of disk granulator
India, Vietnam, Kazakhstan, Mongolia, Ecuador, Iran, Pakistan, Australia, the Middle East and other countries and areas.

5.Main technical parameter of disk granulator

Type	Dia. (mm)	Slope (° )	Speed (r/min)	Power (kW)	Weight (kg)
ZKL(T)-600	600	0 ~ 30	0 ~ 45	2.2	380
ZKL(T)-800	800	0 ~ 30	0 ~ 37	3	500

Type	Pan				Power (kW)	Weight (kg)
	Dia. (mm)	Height (mm)	Slope (° )	Rotating Speed (r/min)
PQ(T)-500	500	160	40 ~ 60	0 ~ 42	0.55	220

6.Profile of ZK Company
Henan Zhengzhou Mining Machinery Co., Ltd is located in Wulong Industrial Park of Zhengzhou Xingyang which is the capital of Henan Province. It is at the junction of 310 State Road and Xingmi Road, close to the highway, railway station, West Zhongyuan Road, downtown area of Zhengzhou and Zhengzhou International Airport. The transportation condition is very convenient. The main products of company include: ball mill, rotary kiln, vertical preheater, cooler, crusher, metallurgical coke oven, magnetic separator, flotation machine, classifier, feeder, bucket elevator, preheater, dust collector, elevator, drier, and other equipments relate to metallurgy, cement, lime, mineral processing, refractory, chemical industry.
The products of Henan Zhengzhou Mining Machinery Co., Ltd have been sold to every province of China and exported to Russia, Korea, Vietnam, Malaysia, Nepal, Bangladesh, Mexico, Armenia, Africa, South America and other countries and regions.

---
