Waste Copper Wire Recycling Machine Copper Wire Granulator scrap PVC Cable Wire Separating Machine

Product Details

Product Description

Product Description
What's scrap copper wire recycling machine?
As the name suggests, scrap copper wire recycling machine is a machine for processing scrap copper wires to recycle copper and plastic. Due to the separated copper looks like rice, it is also called copper wire granulator machine.
What equipment is included in scrap copper wire recycling machine?1. Double-shaft shredder
Double-shaft shredder is used to preprocess the scrap copper wires, to shred copper wires into small pieces and cut off the plugs on the copper wires. It is made of H-13 alloy, which has high hardness and toughness, and can be used for a long time than other shredders.
2. Blade crusher
Blade crusher can crush the small copper wire pieces into small particles. It is made of SKD-11 alloy, which makes the crusher has high hardness of HRC58, good toughness and high wear resistance.
3. Air separator
Air separator is used to separate copper from plastic according to their different density via wind and vibration. The separating rate can reach to 97%-98%.
4. Electrostatic separator
Electrostatic separator adopts a high voltage electrostatic separation technology to separate fine copper in the plastic with the separating rate of 99%. In a closed high temperature magnetic field, copper is easily to be separated from plastic due to their different conductivity.
5. Dust removal system
Since there is a lot of dust and other magazines on the scrap copper wires, dust removal system is needed. Common dust removal system includes pulse dust removal, cyclone dust removal and bag dust removal system.
How does scrap copper wire recycling machine work?
The whole working process of scrap copper wire recycling machine includes shredding, iron removal, crushing, air separation, line-vibrating screen, electrostatic separation and dust removal.
What type of copper wires can be processed?
Scrap copper wire recycling machine can handle nearly all the waste wires you have seen, communication wires, household wires, car wires, computer wires, buried cables, armored cables, etc. whether copper wire or aluminum wire.
What products can we obtain finally?1. Copper
The first final product of scrap copper wire recycling machine is copper with high purity and good quality, which can be sold with a considerable profit in the metal trading market, or it can be made new products, like copper ingots, copper electrolysis, and then sell.
2. Plastic
The other final product is plastic. As for plastic, it can be sold directly as well. Or you can pellet the plastic into other products, like wire cover, tray, blister sheet, mouse, keyboard, etc.
[ Recommended reading: Investment-profit analysis of copper wire granulator machine ]
What's the features of scrap copper wire recycling machine?1. Only 1-2 workers need to operate, save labor, occupy less land, and invest less;
2. PLC control system, easy to operate, smooth performance;
3. Double separation process, high separating rate of 99%;
4. Dry type physical separation, no water, no dust, no fire, and no gas to environment.
5. Large handling capacity, suitable for large scale production.
Henan Doing is the experts in the filed of e-waste recycling. We can not only provide scrap copper wire recycling machine, but also PCB recycling machine and radiator recycling machine. Before delivery, all of our machine will use the material tests that customers need to deal with to ensure that the performance and production of the production line meet the customer's requirements. We sincerely invite customers to come to the site for final testing.

---
