Granite Cutting Tools Saw Blade Diamond Segments for Marble Stone

Product Description

Product Description
1. The blade has good sharpness and high efficiency at the process of cutting, meanwhile, it has a long lifespan.
2. Good cutting result: smooth cutting, flat surface and even size.
3. Stable cutting, narrow cutting gap, stone waste reduction.
4. M-shape segment is easy for diamond opening.

Product Name	Diameter (mm)	Steel Core Thickness(mm)	Segment Dimension(mm)	Segment Number	Application
Edge Cutting Segment For Stone	300	2.2	40x3.2x10(15,20)	21	Granite, Marble, Basalt, Volcanic, Lava Stone, Andesite, Travertine, Limestone, Sandstone, Quartz, Artificial Stone, Microcrystal Stone
	350	2.2	40x3.2x10(15,20)	24
	400	2.6	40x3.6x10(15,20)	28
	450	3.0	40x4.0x10(15,20)	32
Splitting Segment For Stone	500	3.0	40x4.0x10(15,20)	36
	550	3.6	40x4.6x10(15,20)	40
	600	3.6	40x4.6x10(15,20)	42
	650	4.0	40x5.0x10(15,20)	46
	700	4.0	40x5.0x10(15,20)	50
	750	4.0	40x5.0x10(15,20)	54
	800	4.5	40x5.5x10(15,20)	57
	850	4.5	40x5.5x10(15,20)	58
Block Cutting Segment For Stone	900	5.0	24x7.0/6.2x13(15,20)	64
	1000	5.0	24x7.0/6.2x13(15,20)	70
	1200	5.5	24x7.4/6.6x13(15,20)	80
	1400	6.0	24x8.0/7.2x13(15,20)	92
	1400	6.5	24x8.4/7.6x13(15,20)	92
	1600	7.2	24x9.2/8.4x13(15,20)	108
	1800	7.5	24x10/9.2x13(15,20)	120
	2000	8.0	24x11/10x15(20)	128
	2200	9.0	24x11/10x15(20)	132
	2500	9.0	24x12/11x20(30)	140
	2700	9.0	24x12/11x20(30)	140
	3000	9.3	24x13/12x20(30)	160
	3500	9.5	24x13.5/12.5x20(30)	180
Other specifications are available upon request.
Silent and non-silent blades are available for choice.

Detailed Photos

Product Parameters
Diamond Segments For Granite:

Diameter (mm)	Segment Size (mm)	Segment Number
Φ300	40*3.2*10	21
	40*3.2*12
	40*3.2*15
Φ350	40*3.4*10	24
	40*3.4*12
	40*3.4*15
Φ400	40*3.6*10	28
	40*3.6*12
	40*3.6*15
	40*3.6*20
Φ450	40*4.0*10	32
	40*4.0*12
	40*4.0*15
	40*4.0*20
Φ500	40*4.2*10	36
	40*4.2*12
	40*4.2*15
	40*4.2*20
Φ600	40*4.8*10	36/42
	40*4.8*12
	40*4.8*15
	40*4.8*20
Φ700	40*5.2*10	42
	40*5.2*12
	40*5.2*15
	40*5.2*20
Φ800	40*6*10	46
	40*6*12
	40*6*15
	40*6*20
900	24*7/6.4*12	64
	24*7/6.4*15
	24*7/6.4*20
1000	24*7/6.4*12	70
	24*7/6.4*15
	24*7/6.4*20
1200	24*8/7.4*12	80
	24*8/7.4*15
	24*8/7.4*20
1300	24*8.4/7.8*12	88
	24*8.4/7.8*15
	24*8.4/7.8*20
1400	24*8.4/7.8*12	92
	24*8.4/7.8*15
	24*8.4/7.8*20
1600	24*9.2/8.4*12	108
	24*9.2/8.4*15
	24*9.2/8.4*20
1800	24*10/9*12	120
	24*10/9*15
	24*10/9*20
2000	24*10.5/9.5*15	128
	24*10.5/9.5*20
	24*10.5/9.5*25
2200	24*11/10*15	132
	24*11/10*20
	24*11/10*25
2500	24*11.5/10.5*15	140
	24*11.5/10.5*20
	24*11.5/10.5*25
3000	24*13.5/12.5*20	160
	24*13.5/12.5*25
	24*13.5/12.5*30
3500	24*14.5/13.5*20	180
	24*14.5/13.5*25
	24*14.5/13.5*30

Our Advantages
Company Profile

Application Machine:

We specialize in manufacturing and supplying a wide range of cutting tools, abrasives, polishing pads, drill bits, milling cutters, and other toolings. Our products include diamond blades, saw blades, grinding wheels, cutting discs, diamond saw blades, abrasives, machine tool accessories like polishing pads, cutting wheels, flap discs, drill bits, milling cutters, end mills, hole saws, diamond segments, diamond core drills, diamond wires, diamond powder, flap wheels, router bits, sanding discs, circular blades, PCD cutters, CBN inserts, end mills, twist drills, slitting blades, PCD tools, abrasive belts and cloths.
Our cutting tools are widely used in metalworking, woodworking, stone/tile/marble/granite cutting and processing, jewelry making, CNC machining centers, and various other industrial applications. We offer solutions for working with materials like steels, nonferrous metals, stones, ceramics, composites and more. Our toolings are designed for operations like cutting, grinding, drilling, milling, polishing on a range of power tools, hand tools, machines like angle grinders, routers, milling machines, grinding machines, polishing machines and others.
Whether it's heavy-duty abrading, precision machining or anything in between, our diverse catalog has the right cutting tools, abrasives, and toolings for the metalworking, automotive, aerospace, construction, stone working and other industries.
