Horizontal Lathe Machine Cp6176L/Cp6276L, Universal Horizontal Gap Bed Type

Product Description

Heavy Duty Horizontal Gap Lathe
Features:
This lathe is a special purpose heavy duty horizontal face lathe
It is suitable for turning the internal/external cylindrical surface, conical surface, end face and so on
With large-diameter, medium length for all kinds of workpieces .
Standard Accessories:
1.Ø250mm 3-jaw chuck for 50B,50L series
Ø325mm 3-jaw chuck for 66B,66L,76L series
2.Thread chasing dial
3.Chip guard for L≤2m lathe
Follow Chipe guard for L≥3m lathe
4.Footbrake
Optional Accessories:
1.Ø630mm Face plate for 50 series
Ø800mm Face plate for 66,76 series
2.Ø400mm 4-jaw chuck
3.Ø20-140mm Small steady rest
4.Ø130-260mm Large steady rest
5.Ø20-80mm Follow rest
6.Ø250mm Drive plate
7.4-position stop for saddle
8.4-position stop for cross slide
9.Micro stop for saddle
10.Quick change tool post
11. Damping washer
12.Taper turning attachment(TTA)
13.Halogen work lamp
14.Digital readout(DRO)
15.CE standard compliance
16.Chuck cover

Specification	Unit	CP6½66L	CP6½76L
Swing over bed	mm	660	760
Swing over cross slide	mm	430	530
Distance between centers	mm	1000,1500,2000,3000,4000,5000 (4000 & 5000 only for CP61 series)
Swing in gap	mm	- 870	- 970
Width of gap	mm	240	240
Width of bed	mm	390
Spindle nose		D8
Spindle bore diameter	mm	105
Morse taper of spindle center		1:20
Spindle speed	rpm	6-1120 (24 steps)
Max output torque of spindle	N.m	1500
Range of longitudinal feed	mm/rev	0.063-6.43 (0.0025-0.25in/rev)
Range of cross feed	mm/rev	0.027-2.73 (0.00106-0.107in/rev)
Lead screw pitch		12mm(metric system)/2 t.p.i(inch system)
Metric threads	mm
Inch system threads	t.p.i
Module threads		0.5-112mm (42 kinds)
Diameter pitch threads		56-1/4DP (45 kinds)
Cross slide travel	mm	360
Top slide travel	mm	200
Section specification of tool post	mm	25×25
Longitudinal rapid traveling speed	m/min	4.5 (50Hz) / 5.4 (60Hz)
Transversal rapid traveling speed	m/min	1.9 (50Hz) / 2.3 (60Hz)
Morse taper of tailstock center		M5
Max travel of tailstock quill	mm	150
Tailstock quill diameter	mm	75
Main motor	kw	11
Rapid travel motor		250W/1360rpm
Coolant pump motor		90W/25L/min
Hercules Machinery Equipment Ltd.

Machine Image

---
