Digital Theodolite / Angle Measureing / Laser Plumb & Laser Pointner

Product Description

Product Description
Telescope

Length of lense	167mm
Image	erect
Objective Aperture	30X
Field of View	1"30'
Resolusion	3.3"
Min-Focusing Distance	1m
Stadia Addition Constant	0

Angle Measuring System

Mode of Angle Measurement	Photoelectric Incremental Reading
Detection Method	H: Dual Side
	V: Sigle Side
Minimum Reading	1" / 5" / 10"
Accuracy	2"
Display	LCD double side

Compensator

Tilt Sensor	Equipted
Range of Compensation	±3'
Minimum Reading	1"
Precision of Angle Measurement	2"

Laser plummet

Laser wavelength	635nm
Accruacy	0.5mm / 1.5m

Base

Base	Detachable
Power
Battery	AA battery * 4
Bubble
Long	30"/2mm
Circle	8'/2mm

Laser System

Laser wavelength	635nm Green / 520nm Red
Laser Power	10mw
Effective range (day)	150m
Optical Diamiter	5mm/100m
Laser Deviation	≤5"
Operating Temperature	-10ºC + 45ºC

Other Specification

Storage Temperature	-20ºC + 50ºC
Weight	4.7kg
