US$800.00-1,250.00 | 1 Piece (MOQ) |
Usable bandwidth (-10dB) | 35Hz - 20kHz |
Maximum SPL | 147 dB |
Coverage angle (-6 dB) | Horizontal: 110°/70° symmetric; 90° asymmetric (35°/55° or 55°/35°) |
Vertical: depends on the number of elements and array curvature | |
Transducers | LF: 2 x 12'', weather-resistant, bass-reflex MF: 4 x 6.5'', weather-resistant, bass reflex HF: 2 x 3'', diaphragm compression driver |
Nominal impedance | LF: 2 x 8 ohms; MF: 8 ohms; HF: 16 ohms |
RMS power handling | LF: 2 x 450W; MF: 320W; HF: 160 W |
Connectors | IN: 1 x 8-pins PA-COM; LINK: 1 x 8-pins PA-COM |
Dimension | 1338 x 354/286 x 400 mm; 52.7 x 14/11.3 x 15.8 in |
Weight (net) | 56kg |
Enclosure | First grade birch plywood |
Finish | Dark Grey brow/ black |
