15.6 Inch IPS1366*768 HDMI VGA AV BNC IPS Monitor Resistive Touch Screen Metal Case TFT Wall Mounted OEM ODM Industrial Factory LCD IPS Monitor

Product Description

Product Description

Datasheet
Model	B156-ZT
Size	15.6"
Active Area	344.23*193.54 mm
Panel Type	IPS Panel
Backlight	LED
Backlight Life	50,000 hrs
Resolution	1366*768
Acpect Ratio	16:9
Contrast	500:1
Brightness	200 cd/m
Viewing Angle (H/V)	170/160
Response Time	25 ms
Display Color	262K
Operating Temperature	0~50ºC
Storage Temperature	-20~60ºC
Video Inputs/Outputs	Audio/ VGA/HDMI/DC input*1
Audio Inputs/Outputs	N/A
Touch	4-wire Resistive
Installation	Stand base/VESA mount
Power Requirement	DC 12V
Dimension (W*H*D)	376*237*13 mm
Weight	3.5 kg
Control	OSD Control
Certificates	CE/FCC/ROHS
VESA wall mount kit/ Hanging ear / Stand , VGA cable/ HDMI cable , USB touch cable, Touch pen, Flash dirve, 12V DC 1A power adapter, Manual , Warranty card

Q: For the first time cooperation, what are the advantages of your company?
A:1. LCD monitor factory since 2004 with rich experience.
2. Our products have a wide range of products and a wide range of product sizes which can meet different application fields and application equipment.
3.The company has good customizable R&D capabilities and supply chain.OEM/ODM supported.
4. Industrial grade panel with durable PCB board,Quality guaranty by QC team.
5. Low ex-factory price, high cost performance, large discounts on Made-in-China platform.
Q: What is your company's main product?
A: Our main product is lcd monitor,metal monitor,Aluminum monitor,Capacitive/Resistive touch monitor,X86/Android all-in-one PC,Complete sizes and resolutions, multiple choices of interfaces and installation methods.
Q: How about the lead time?
A: They depends on the quantity of your order.As you know .we need time to manufacture the machines.but mostly ,the shipment time is 3-8 working days after delivery.As for detailed cost, it depends on your final order.
Q: What payment term do you support?
A: We accept most of the payment methods,mainly accept T/T ,VTB,PAYPAL, Made-in-China assurance trade payment.
Q: What's your warranty?
A: All of our products share 12 months warranty, On-line service and additional accessories supported.(Except for human factors)

---
