Product Details
Product Description
Product Description
Double-direction thrust ball bearing can carry axial loads in double directions, but it can not carry radial load. Double-direction thrust ball bearings can make an axial location in two directions. Double-direction thrust ball bearings also have planar housing washer and self-aligning seat washer. Generally, planar housing washer cannot allow any angular error, however, when designing bracing structures, a gap of 0.5-1mm between the outer diameter of housing washer and the fitting surface of bearing block can be kept to correct the angular errors, which, would be made when mounting. Self-aligning housing washer need to be ordered and manufactured separately.
Specification:
Manufacturer Product Code:2327/1049YA
Original Bearing Code:2687/1049
Basic Product Description:Thrust ball bearing
Bore Type:Straight
Measurement:Metric
Clearance:Normal
Precision:P0;P6;P5
Cage:Cast iron
d(mm):1049.5
D (mm):1270
Width H (mm):220
Weight (Kg):428
Sealing:Open (No seal)
Rotary Table Bearings
For Rotary Table ZP175
Bearing No.: 5692/530, 5617/520, NU2322EM, 22322CA C3W33
For Rotary Table ZP205
Bearing No.: 5692/650X1/YA3, 5617/620, NU2330EM, 22330CA C3W33
For Rotary Table ZP275
Bearing No.: 5692/800, 5611/800, 22330CA C3W33, NU2330EM
For Rotary Table ZP375
Bearing No.: 2327/1049YA, NU2330EM, 22330CA C3W33
>>
