Product Description
Product Description
Small Hole Expanded Metal Mesh
view more, click here.
To my dear customer
Dear Customer,
Welcom to our website and hope our expanded metal mesh will make you satisfied.
We think creatively, design bravely, manufacture precisely and loyalty to our customers.
And we have our own factory. So we can produce the expanded metal mesh according to your requirements.
We are looking forward to establisheing cooperation with you.
Your Sincerely
Dongjie
Product Description
Expanded metal is an intermediate raw material that allows light and air to flow freely through it and that has more rigidity than the sheet from which it was produced.
It is formed in an expanded metal press and produced from any malleable metal sheet product. The plate, sheet, or coil is simultaneously slit and stretched into diamond-shaped openings. These openings are of uniform size and regularity.
Styles of Expanded Metal
Regular (standard or raised) – all expanded metal is produced in regular form off the expanders. The strands and bonds are set at a uniform angle to the plane of the sheet. This gives added strength and rigidity, as well as a skid resistant surface.
Flattened – is manufactured by processing regular expanded metal in a rolling mill. The rolling process reduces the thickness of the original base metal.
| Small Hole Expanded Metal Mesh |
| Materials | * Carbon Steel * Aluminum * Stainless Steel
* Galvanized * Copper * Brass
* Titanium *Platinum * Zinc
* Nickel * Silver * Gold
|
| Surface Treatments | * hot-dip galvanizing *pre-galvanizing
*anodizing, enameling *power coating
*painting *plastic coating, etc.
|
| Hole Patterns | *Diamond *square
*round *triangle *scale
|
| Benefits | *The “Flow” of Light and Air
*Design Customization
*Design Flexibility
*Strength and Formability
*Durability *Cost Effective *Cost Effective
|
Design Designations
Strands – The sides of the expanded metal design
Strand Thickness – Thickness of the base material from which the sheet was produced.
Strand Width – Amount of metal fed under dies to produce one strand
Strand Thickness and Width – Can be varied to create different openings.
The width of the strand should equal or exceed the thickness of the base metal.
SWD – Nominal dimension, Short Way of Diamond
LWD – Nominal dimension, Long Way of Diamond
Design Size – Actual dimension SWD and LWD.
Measured from a point to a corresponding point on the adjacent diamond.
SWO – Short Way of Opening
LWO – Long Way of Opening
Bond – Where two strands intersect
Product Images
Product Process
Applications
Air and fluid filters
EMI/RFI shielding
Battery cells
Ventilation systems
Strainers
Satellite and radar antennas
Partitions
Outdoor furniture
Speaker grills
Security walls, ceilings, floors, doors
Machine and window guards
Fencing
Packing and Delivery
To protect theexpanded metal mesh well, goods are packed with different materials.
Expanded metal mesh in rolls: wrapped by waterproof paper
Expanded metal mesh in panels:in pallets
Expanded metal mesh in pieces:in carton
Our Service
1. Small sample is free.
2. According to the different customer need to customize logo.
3. According to the color of the customers like to customize.
4. We have full stock, and can deliver within short time.
5. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.
We have rich experience of design, manufacture and sell solar water heater, we cherish every order from our honor.
Our Certifications
Why Choose Us
1. Professional
Over 20 years' experience i wire mesh industry and export more than 70 counries. Dongjie Wire Mesh is the real professional manufacturer.
2. Product Quality
The quality of product is the key of the survival of enterprise . Dongjie Wire Mesh is a ISO9001:2008 certificated manufacturer.
3. Reasonable Price
We'll exactly control each producing process to reduce cost for our customers. After clients receiving the quotation, we 'll show you the rational priceand the difference between our products and other suppliers' products.
4. Delivery Time
We'll make a produciton plan before producinig, and the sales will regularly inform the production schedule and process to the customer.
5. Communication
English is the basic language and other language also can be understood. All customer's e-mail will replied within 2 hours at working hours and must be replied within 12 hours at non-working hours.
6. Customized
Personalized, professional service: We can provide different programs according to customer's requirement, thus make customers choose the best and appropriste one.
Customer Review
FAQ
1. How to make an inquiry of Wire Mesh?
You need to provide material, wire diameter, size and the quantity to ask an offer. You can also indicate if you have any special requirement .
2. Could you provide free sample?
Yes, we can provide free sample in half A4 size together with our catalogue. But the courier charge will on your side. We'll send back the courier charge if you make an order.
3. How is your Payment Term?
Generally, our payment term is T/T 30% in advance and the balance 70% against the copy of B/L. Other payment term we can also discuss.
4. How is your delivery time?
We always prepare enough stock material for your urgent requirement, the delivery time is 7 days for all the stock material.
We'll chack with our production department for the non-stock items to offer you the exact delivery time and producing schedule.
Our Company
Anping Dongjie Wire Mesh Product Co., Ltd is a premier manufacturer and supplier of wire mesh products located in Anping Town, the famous Wire Mesh Land of China. We have engaged in expanded metal mesh, perforated metal mesh, decorative wire mesh and stamping parts for decades and have accumulated rich experiences in this field.
