5-Axis CNC Machining Center 5 Axis Milling Machine Center (fresadora CNC)

Product Description

One-stop Shopping
Please click on the picture to view the product category you are interested in

Conventional Lathe	CNC Lathe	CNC Machining Center	CNC Milling Machine
Grinding Machine	Milling Machine	Special Use Lathe	Boring Machine

Product Description
5 axis vertical machining center

SPECIFICATION		FMC400	FMC630
Travel	X-axis Travel(mm)	450(-225~+225)	700(-350~+350)
	Y-axis Travel(mm)	500(-250~+250)	780(-360~+420)
	Z-axis Travel(mm)	450(+50~+500)	550(+80~+630)
	A-axis Travel(°)	-120~+30	-120~+30
	C-axis Travel(°)	nx360	nx360
Worktable	Type	Direct Drive	Direct Drive
	Worktable Dim.	Φ400	Φ630
	Worktable Max. Load Capacity-Milling(kg)	350	1200
	Worktable Max. Load Capacity-Turning(kg)	175	600
	Max. Turning Dia.(mm)	Φ600	Φ850
	Distance from A-axis Center to Worktable Face(mm)	0	80
	A/C-axes Locking Mode (Pneumatic/Hydraulic)	Pneumatic	Hydraulic
Spindle	Spindle Type	Electric Spindle	Electric Spindle
	Spindle Taper Hole Size	HSK-A63	HSK-A63
	Spindle Power(KW)	S1/S6-40%:25/40	S1/S6-40%:25/40
	Spindle Torque(Nm)	S1/S6-40%:87/135	S1/S6-40%:87/135
	Spindle Max. RPM(r/min)	20000	20000
	Spray Cutting Fluid Function from Spindle Center	Available	Available
	Rigid Tapping Function	Available	Available
Speed	X/Y/Z-axes Fast Moving Speed(m/min)	60/60/60	60/60/60
	A/C-axes Fast Moving Speed-Milling(r/min)	100/120	80/120
	A/C-axes Fast Moving Speed-Turning(r/min)	100/2000	80/850
Positioning Precision	X/Y/Z-axes Positioning Precision(mm)	0.005/0.005/0.005	0.006/0.006/0.006
	A/C-axes Positioning Precision(″)	7	7
Repeat Positioning Precision	X/Y/Z-axes Repeat Positioning Precision(mm)	0.003/0.003/0.003	0.004/0.004/0.004
	A/C-axes Repeat Positioning Precision(″)	4	4
Tool Magazine	Tool Magazine Type	Umbrella Type Tool Magazine	Umbrella Type Tool Magazine
	Tool Capacity(Pc)	22	30
	Max.Tool Weight(kg)	6	6
	Max. Tool Dia.(mm)	Φ80	Φ80
	Max. Tool Length(mm)	250	300
Machine Tool Dim.	Machine Tool Floor Area (Length×Width×Height)(mm)	3450x4155x2925	4170x4715x3510
	Machine Tool Weight(t)	6.2	12

Mechanical Structure

Integral Gantry Structure Casting Machine Body The machine tool base and column are cast in an integrated structure	Intermediate-driven Triangular Support Beam Four guide rails support and the main drive located in the center for Y-axis.
Left-right Symmetric Structure Reduce the thermal deformation during the mechanical movement.	Layout Scheme of Stepped X-axis Guide Rail Increase the guide rail span and improve the rigidity
The tool magazine is located in the machine body inside Compact Structure and Space Saving.	High-precision Linear Encoder and Encoder as Standard Configuration Check the absolute position of each axis to realize full closed-loop control
Aprecision roller guide rail and ball screw	Spindle Thermal Compensation Reduce the machining error of spindle caused by thermal deformation

self-developed turntable
A/C-axes adopt the direct drive technology, which can achieve high speed, big torque and good dynamic response, without reverse clearance and transmission mechanical wear.
C-axis can be equipped with high-speed torque motor for turning.
4-way hydraulic/pneumatic interface as the standard configuration of turntable can meet the requirements of automatic fixture Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

---
