| US$10,500.00-18,500.00 | 1 Piece (MOQ) |
| NA Series | NA-48 | NA-510 | NA-2040 |
| Table Area | 1220×2440mm | 1525×3050mm | 2000×4000mm |
| Traveling Area | 1320×2540×300mm | 1625×3150×300mm | 2100×4100×300mm |
| Traveling Speed | 80m/min | 80m/min | 80m/min |
| Working Speed | 20m/min | 20m/min | 20m/min |
| Spindle Power | 9.0kw/12KW | 9.0kw/12KW | 9.0kw/12KW |
| Spindle Speed | 24000r/min | 24000r/min | 24000r/min |
| Working Voltage | AC380V/3PH/50HZ | AC380V/3PH/50HZ | AC380V/3PH/50HZ |
| Driving System | Yaskawa / Siemens | Yaskawa / Siemens | Yaskawa / Siemens |
| Controller | Syntec / Siemens /OSAI | Syntec / Siemens /OSAI | Syntec / Siemens /OSAI |
| Positioning Mode | Pop-up positioning pin | Pop-up positioning pin | Pop-up positioning pin |
| Table Structure | Vacuum | Vacuum | Vacuum |
| Tool Magazine | Linear / Carousel | Linear / Carousel | Linear / Carousel |
| Optional | Automatic loading & unloading system / Safety protection guard / Drilling / Double station/ B Axis / | ||
| C Axis / Aggregate head / Vacuum cup / Partition table / Vacuum pump / Hold-down device, etc | |||
