Professional Manufacturer Plasterboard Gypsum Plaster Board Plant Production Line

Product Description

Professional Manufacturer of Gypsum Plaster Board Plant Production Line Process description

Material needed
Gypsum powder, paper, modified starch, foaming agent

Cost composition	Unit	Quantity
Face protection paper	Kg	0.36
Gypsum powder	Kg	5.6
Modified starch	Kg	0.04
White latex	Kg	0.006
Foaming agent	Kg	0.003
coal	kg	0.61
Electricity	kw	0.3
water	Kg	4
Cover paper	yuan	0.1
Labor and management fees	yuan	0.25

2. Fuel:
Natural gas, diesel, heavy oil or coal
3. Product specification:
Length: 2400mm~3600mm
Width: 1200mm or 1220mm
Thickness: 8mm-20mm(can be adjusted)
Production process

Paper supply system
It has the unique way of splicing and high-density correction institutions, what's more, the nick played a very helpful role for the further plastic and trimming. Quality of the product can be greatly improved, and reduce a lot of unnecessary waste, thus reducing costs.

Powder supply system
It has the core of unique quantitative feeder, the supply of gypsum powder to make very precise which provides a great convenience for the further mixing, coupled with pneumatic discharge device so that a reliable supply protection for the feed powder.
Water supply system
About this water supply system using hot water switch, the product not only improves the strength quality, but Oslo save the energy, adopt the professional accuracy pump water provides a great convenience.

Foam system
This system uses a unique barostat supply, dedicated pump for the foam, and the bubble into the liquid to a uniform paste, for the operation provides great convenience, and therefore the weight of the product easier to adjust master.

Forming system
The introduction of foreign technology, use of special stainless steel strong edge pneumatic vertical mixer with special stainless steel plate forming machine, so that the system greatly enhanced wear resistance, longer service life. Replaced by the original plate forming machine roll lamination, improved the smoothness f board.

Convey system
Except the conventional conveyor system, a further increase in the waste plate cleaning machine, not only reduces the labor intensity, but also to plant sanitation and clean.
Transmit system
It is the most advanced non-powered fast-forward into the body panels to reduce energy consumption, and the various parts of assembly are improved overall, more reliable operation of the machine.

Drying system
The drying system is the core set of production lines, it directly affects the production line output and energy consumption, this system adopts the unique radiator structure, may layer temperature control, section temperature control, plus new and unique air system, so that the temperature and humidity levels of the system is adjustable, which played a role in reducing energy consumption and make the operation of the system easier to grasp, is the key to reducing test costs.

Length system
The system with a unique flap machine and palletizing unit became the latest length system, thus ending the history of artificial cut-off plates, lower labor cost.

Company Profile
Shijiazhuang Wuxing Mechanical Co., Ltd established in 2005, is a professional manufacturer engaged in the research, development, production, sale and service ofgypsum board production line, Gypsum powder production line, calcium silicate board production machine and Light Mineral Wool Board production machine. We are located in Shijiazhuang city with convenient transportation access. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. In recent years, our company has introduced a series of advanced equipment. In addition, we have obtained ISO 9001, CE certificates. Selling well in all cities and provinces around China, our products are also exported to clients in such countries and regions as Russia, the Middle East, Eastern Europe, and South Asia. We also welcome OEM and OD Morders. Whether selecting a current product from our catalog or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements. Wuxing will take the "creating value for customers" as our own responsibility, adhere to the "integrity-based, mutual benefit and win-win" principle, and provide professional technology and omni-directional series of services for our partners.
What is your advantage and service?
Firstly, we own up-to-date technology and experienced research and develop team, provide you with strong technical support.
Secondly, we provide free design, including plant layout, equipment diagram according to your demand.
Thirdly, we supply all support for raw material supplier information.
Fourthly, arrange practiced technicians installing and training oversea as soon as you receive the machines.
More pics and videos, please contact freel

---
