Top Closed Loading Arm Al1411 Factory Price

Product Description

The structure of A1411 land loading arm:
Our land loading arm in workshop:
LDCO's loading arm on sit:
General introduction for land loading arm:
Our land loading arm is especially designed for transporting fluid between piping system and tanker, which shall be designed for different tanker, liquids and site conditions.
Equipped with loading platform, folding stairs and safety cage to make the land loading arm into a complete loading system.
By level location or quantitative monitoring, while fluid level exceed the present value, provide the sound and visual alarm or the remote signal.
According to the products, models and requirements of customers, the operating modes could be manual, pneumatic or hydraulic etc.
Basic technical data:

AL1411 is a typical of closed loading arms. It can be easily operated, installed and maintained and has good vapor recovery ratio.
Places Applied	Closed top loading
Applications	Product oil, chemicals, especially for highly valatile and toxic liquids
Nominal Diameter	DN50~DN150 (liquid), DN25~DN100(gas)
Working Temperature	-196~250ºC
Working Pressure	PN1.0~PN4.0
Material of pipeline	Carbon steel, stainless steel, aluminum, low-temperature steel, PTFE lined etc.
