| Number | Project | Company | Parameter | Remarks | |
| 1 | Full length (fork square ground) | mm | 10450 | ||
| 2 | Full width | mm | 3400 | ||
| 3 | Full height | mm | 4200 | ||
| 4 | Load center distance | mm | 800 | ||
| 5 | curb weight | kg | 50000 | ||
| 6 | Rated load | Kg | 50000 | ||
| 7 | Maximum lift fork height | mm | 3000 | ||
| 8 | Maximum lifting height of fork rack | mm | 4340 | ||
| 9 | Maximum front suspension | mm | 1730 | ||
| 10 | No-load/full-load maximum hoisting speed | mm/s | 250 / 170 | ||
| 11 | No-load/full-load maximum descent rate | mm/s | 160 / 180 | ||
| 12 | Maximum forward/backward inclination of fork | ( °) | 23 / 15 | ||
| 13 | Fork (L*W*T) | mm | 1600X320X140 | ||
| 14 | Fork adjustment range | mm | 3000 | ||
| 15 | Steering angle (L/R) | ( °) | 30 / 30 | ||
| 16 | Turning diameter | mm | 20000 | ||
| 17 | Minimum ground clearance | mm | 520 | ||
| 18 | ）Gradient of climbing (full load) | ( % ) | 25 | ||
| 19 | Maximum traction force | kN | 270 | ||
| 20 | Wheelbase | mm | 4750 | ||
| 21 | Tread (front / rear) | mm | 2590 / 2590 | ||
| 22 | Front suspension (minimum) | mm | 1480 | ||
| 23 | Rear suspension distance | mm | 2590 | ||
| 24 | Departure angle | ( °) | 21 | ||
| 25 | Running speed | Forward I / II | Km/h | 12.0 / 22.0 | |
| Back file I / II | 14.0 / 20.0 | ||||
| 26 | Engine | WD12G336E211 | 247kW | ||
| 27 | tyre | 4×29.5-29-46PR | |||
| 28 | Two variable assembly | ||||
