| US$18,500.00-21,000.00 | 1 Set (MOQ) |
| Model number: | UVLED-L900 |
| Exposure light source: | High-power ultraviolet LED array lamp set |
| Alignment uniformity: | More than 90% |
| Exposure way: | Namely bright control |
| Exposure select: | Single / double-sided exposure |
| LED lamp life: | ≥three years |
| Vacuum device: | Oil-free vacuum pump, vacuum degree of 90 kpa |
| Cooling-down method | Forced air cooling type |
| Exposure energy control: | duration control |
| Effective exposure area: | 900mm*650mm |
| Resolution : | 1,2mil,thickness of dry film ≤20um; 2,3mil,thickness of wet film≤20um,thickness of dry film≤40um |
| Mesa structure | Merra membrane + optical glass |
| control system: | Japanese omronPLC + HMI control |
| Operation interface: | Chinese and English pictures, 4 groups of exposure time selection, exposure power 10% -100% infinite adjustable |
| Major structure: | Standard board electrostatic spraying paint |
| Safe guard : | Abnormal emergency stop, overtemperature protection, overcurrent protection, short-circuit protection, leakage protection |
| Electricity demand: | AC220V 50Hz 3KW single phase |
| Environmental requirements: | Temperature 22-25ºC,humidity 55-60%,Dust-free requirements for level 10,000 |
| Outline dimension: | L1450*W2900*H1700mm |
| Weight of equipment: | 900KG |
| Equipment advantage: | 1, add secondary optics, parallel optical structure, good exposure accuracy, high yield.. |
| 2, equipped with light gate to prevent ultraviolet leakage, protect the health of operators. | |
| 3, copper-based PCB light board, good heat dissipation, high lamp source life. | |
| 4, Korea LG / SVC imported high-power UV LED, high light efficiency, long life and stable performance. | |
| 5, Japan omron program controller, Japan Panasonic sensor, to ensure the equipment. | |
| 6, equipped with Taiwan high-power oil-free vacuum pump, high vacuum degree, will not produce secondary pollution. | |
| 7, the disassembly frame design structure, the replacement more quickly. | |
| 8, use the intelligent touch screen and PLC automatic control program, all Chinese display. |
