Automatic Control Stainless Steel Mechanical Extrusion of Petroleum Resin Rosin Particle Forming Machine

Product Description

Product Description
Automatic control stainless steel mechanical extrusion of petroleum resin rosin particle forming machine
A grain wax molding machine is a device specially designed to process grain wax into a specific shape or to further improve the properties of grain wax.
Major component
Feeding system: usually consisting of a hopper and a conveying device. The hopper is used to store the grain wax to be processed, and its capacity depends on the production scale of the machine, the hopper of the small grain wax molding machine may hold dozens of kilograms of grain wax, and the large one can hold several tons.
Forming system: The need for shape regulation may include rolling devices with multiple screens or molds of different apertures and shapes. Can be made into block, plate and other special shape of granular wax products to meet the needs of different industries.
Heating and cooling system: heating methods are generally resistance heating and steam heating. Water cooling is to let the cooling water flow through the cooling pipe or cooling jacket, take away the heat of the wax, cooling speed.
Control system: Modern wax molding machines are equipped with advanced control systems to ensure the stable operation of the equipment and the precise control of the production process.
Product Parameters

specification	Minor	1000mm×600mm×1200mm
	middle	2000mm×1000mm×1800mm
	large	5000mm×2000mm×3000mm
weight	Minor	200-500kg
	middle	1-3t
	large	>10t
Dynamic system	Motor power	1.5kw-30kw
	Rotational speed	1400r/min 2800r/min
	Transmission mode	Belt/gear/chain drive
Heating system	Minor	3-8kw
	middle	10-20kw
	large	30-60kw
	temperature	50 degrees Celsius -150 degrees Celsius
Cooling system	Motor power	0.3-3kw
	Air cooling system	5-10min
	Water cooling system	2-8min
Productive capacity	Minor	10-50kg/h
	middle	100-500kg/h
	large	1000kg/h
Particle size	1-10mm

Company Profile
Dongguang Tiancheng Machinery Factory, located in Chengnan Development Zone, Dongguang County, Cangzhou City, Hebei Province, 50 meters away from National Highway 105, 3 kilometers away from Beijing-Taiwan Highway,
The traffic is very convenient, the factory covers an area of 20 acres, construction area of 5000 square, with perfect cold and hot processing capabilities, the existing various precision processing equipment 30 sets, with a variety of precision machining capabilities, the existing staff of more than 40 people, including 6 engineering and technical personnel, advanced production equipment, perfect testing means, in petrochemical machinery has a good reputation, Well received by users.
The main products of our factory are: a complete set of benzol dewaxing refining equipment and technology, casing crystallizer, plate wax forming machine, particle forming machine, tower granulation, scraper forming machine, rotary condensing granulator and so on. The company has obtained a number of national patents, products sold at home and abroad and a number of large and medium-sized petrochemical enterprises.
Our factory will, as always, adhere to the "customer first, quality first, reputation first, service first" business purpose, strive to pursue excellence, and create brilliant results, welcome new and old customers to visit the company guidance exchange.
