High Cutting Speed Servo Wirecutting EDM Machine Hq-630GS

US$18,888.00 1 Piece (MOQ)

Basic Info.

Model NO.
HQ-630GS
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
+-0.0025mm
Performance Classification
High-End CNC Machine Tools
Certification
CE, ISO 9001
Condition
New
Driver
Servo Motor, Screw Error Compensation
Transport Package
Plywood
Specification
HQ40GZ-AS
Trademark
HANQI EDM
Origin
China
HS Code
84561090
Production Capacity
600 Sets

Product Description


The first domestic company puts the servo WEDM-MS into scale production, best choice for you to replace low-end stepper ones.
Widely used in mold manufacturing, profile, military academies and other industries.
The most widely used and favored product on the market. High quality casting, multiple tempering. "C" frame structure , "T" shape bed, ensuring the stability for a long time. U, V axes cross slide designed, compact structure.
HQ-400GS HQ-500GS HQ-630GS HQ-800GS
Machine
Machine size mm 1680*1200*2300 1810*1350*2300 2100*1450*2400 2300*1600*2400
Weight kg 2000 2500 3000 3800
diameter of wire mm φ0.12-0.20 φ0.12-0.20 φ0.12-0.20 φ0.12-0.20
Power kw ≤2.3 ≤2.8 ≤3 ≤3.5
Workingtable Size
Worktable travel(X/Y/Z) mm 400*320*300 500*400*300 630*500*300 800*630*300
Worktable size mm 660*450 720*520 880*600 1050*650
Working tank size mm 980*550 1180*710 1310*795 1400*940
Maxworkpiece weight kg 400 500 700 800
Generator
Drive Mode AC servo AC servo AC servo AC servo
Best Surface Roughness um Ra≤0.7 Ra≤0.7 Ra≤0.8 Ra≤0.8
Max cutting height mm 300 300 300 300
Max Taper °/mm ±6°/80 ±6°/80 ±6°/80 ±6°/80
Max Machine Speed mm²/min ≥220 ≥220 ≥220 ≥220
Wire speed frequency frequency frequency frequency
System
Hardware Fanl-free industrial computer,32G industrial SSD, Standard computer keyboard
Communication USB,LAN,RA232
Axis control 4 axis simultaneous, lifting of guide wire is controlled.
Language Chinese, English, Russian, Japanese
Power Supply 380v±10%,50/60Hz,2kVA

Wire Cut EDM Machine Key Parts List
Linear guideway HIWIN P3 grade linear guideway
Ball screw HIWIN silver C3 grade precision ball screw
Wire drum HIWIN P3 grade linear guideway
U, V axis taper device HIWIN P3 grade linear guideway
Bearings Germany NEY precision bearing
Computer Special industrial computer
Display Industrial Display
Electrolytic capacitors Japan Ruby or King Kong
X, Y axis servo motor Japan Panasonic AC servo motor
Wire guider Special type diamond guider for wire
Filtration systems Brass WEDM type water filter
Z-axis electric lift Electric type
Guide wheel Special thickness guide wheel
Multifunction fixture Brass WEDM type fixture
High-strength body structure T sharp machine bed
Wire constant tension device 2 sets constant tension device
High frequency pulse power Japan technology, high speed, low roughness
Electrical Schneider
