50000 Liters Propane Gas Storage Tank for LPG Station Plant 25 Tons LPG Bullet Storage Tank

US$14,200.00-19,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

CLW6085

Material

Carbon Steel

Pressure

1.6MPa≤p<10.0MPa

Storage Medium

Flammable/Toxic

Pressure Level

Medium Pressure (1.6MPa≤p<10.0MPa)

Condition

New

Tank Material

Q345r

Loading Capacity

50cbm, 50000liters, 25ton

Shell Thickness

14mm

End Thickness

16mm

Tank Diameter (mm)

Dn2800, Dn2700

Design

1.71MPa, 17.7bar

Hydraulic Test Pressure

2.21MPa 22.1bar

Corrosion Allowance

1 mm

Life Time

20 Years

Composition

Propane, Butane

Usage

LPG Gas Storage, Station Tank

Logo

as Customer′s Request

Warranty

One Year

Transport Package

Naked, Waxed

Specification

9182 x 2728 x 3318 mm

Trademark

CLW

Origin

Suizhou, China

HS Code

73110090

Production Capacity

500 Unit/Month

Product Description

50000 Liters Propane Gas Storage Tank for LPG Station Plant 25 Tons LPG Bullet Storage Tank
Product Description
1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc
2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP,
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.
50000 liters Propane Gas Storage Tank

50 CBM LPG TANK DIMENSIONS
Volume of Tank		50 CBM
Filling Weight		19950kg
Tank Weight		10910kg
Thickness of Shell (mm)		14 mm
Thickness of End plate (mm)		16 mm
Tank Diameter (mm)		2700 mm
External Dimensions (mm) (length x width x height)		9912 x X2628X3218 mm
Material of Tank and Main Pressure Parts		Carbon Steel Q345R
Filling Medium		Liquefied Petroleum Gas ( Propane)
Design Pressure		1.77 MPa / 17.7Bar
Corrosion Allowance		1 mm
Medium Density		500 kg/ cbm
Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China.
Main parts of LPG Tank
Item	Specification		Quantity
Discharge Pipe	DN80		1
Inflow Pipe	DN80		1
Gas phase balance pipes	DN50		2
Drain Hole	DN50		1
Manhole	DN450		1
Air-out Pipe	DN50		1
Safety Valve Pipe	DN80		2
Safety Accessories (Included in the quotation): Cut-off Valve, Needle Valve, Safety Valve, Magnetic Liquid level meter, Pressure gauge, Temperature Gauge.

Product Diagram
Product Process

Company Introduction
Overseas Exhibition and Local Support
Customer Visiting
Contact Alice for more details
