Brass Ball Valve 1/4" to 4" 600psi NPT Bsp Thread Hot Forging

Product Description

Product Description
Brass Ball Valve 1/4" to 4" 600PSI NPT BSP Thread Hot Forging

TYPE	Brass Ball Valve 1/4" to 4" 600PSI NPT BSP Thread Hot Forging
Material	Brass Forging
SIZE	DN15 DN 20 DN32 DN40 DN50 DN65 DN80 DN100
Applicable medium	Firefighting, Piped Water
Medium temperature	≤100ºC
Operating Pressure	≤1.6MPA
Sealing Material	FKM Fluorine Rubber Hard Seal

A ball valve is a form of quarter-turn valve which uses a hollow, perforated and pivoting ball to control flow through it. It is open when the ball's hole is in line with the flow and closed when it is pivoted 90-degrees by the valve handle.The handle lies flat in alignment with the flow when open, and is perpendicular to it when closed, making for easy visual confirmation of the valve's status.Ball valves with mounting pad can also be operated by actuator and gear box. Ball valves are durable, performing well after many cycles, and reliable, closing securely even after long periods of disuse. These qualities make them an excellent choice for shutoff and control applications, where they are often preferred to gates and globe valves, but they lack their fine control in throttling applications. Descriptions:Brass Ball Valve 1/4" to 4" 600PSI NPT BSP Thread Hot Forging 1) Design standard: ASME B16.34, API608 2) Threads ends: ANSI B1.20.1,BS 21/2779,DIN 259/2999,ISO 228 3) Testing: API 598 4) Material:brass
5) Size: 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2",2-1/2" ,3" ,4" 6) Working pressure: 1000 PSI,PN63 7) Seat Material: PTFE,RPTFE,PPL 8) Working temperature: -20 to 180°C(PTFE) ,-20 to 300°C(PPL) 9) Working medium: Water, Oil, Gas, Steam, Acid, etc Features: 1) Blow-out proof stem 2) Investment Casting Body 3) Pressure Blance Hole in Ball Slot 4) Reduce Bore 5) Threaded type: NPT,PT,BSP,BSPT,DIN is available 6) Locking device is available
Warehouse
Packing & Delivery
1.Packing Details : carton+plywood pallets/cases+container. 2.Standard exporting cartons and plywood pallets/cases.
3. According to the customer's requirement.
4.Delivery Details : 15-30 days after confirming order.
Company Profile Qingdao Fluido. is one of the biggest manufacturers and exporters of pipeline products in China. We specialize in pipeline products, casting and forging (with or without machining): Malleable iron pipe fittings, ductile iron grooved fitting and coupling, 125# cast iron pipe fitting, steel butt-welding pipe fitting, steel flange, forged steel pipe fittings, stainless steel threaded pipe fitting, steel pipe nipple & merchant coupling, steel pipe, brass pipe nipple and bronze fitting, cast iron soil pipe and fitting, resilient seat non-rising stem wedge gate valves, check valve, butterfly valve, brass valve and bib-cock, scaffolding couplers / clamps, scaffolding frame & props, scaffolding accessories, pipe clamp fitting, concrete lifting anchors, lifting insert, socket & fixing insert, concrete hardware accessories, expansion shell, pipe coupling & hose clamps, radiator, cast iron manhole cover, auto parts, sand casting parts, investment (lost wax casting) casting parts, die casting parts, and kinds of casting and forging machinery parts according samples or drawing from customers. All our factories are certified to the international ISO-9001 quality system standard and all products are carefully tested to meet the strict quality requirements and industry standards prior to each shipment. Parts of our products have been tested, listed, approved by some predominant labs and bodies. In order to enhance our accountability for environment, the environmental management system to ISO14001 has been assessed and registered by BVQI (France). Any information, samples and drawings which you can provide will facilitate us to make the correct supply to meet your special requirements.
Certificates
Related products
FAQ
1.Who are we? We are based in Shandong, China, start from 2004,sell to South America(25.00%),North America(25.00%),Mid East(20.00%),Eastern Europe(20.00%),Western Europe(5.00%),Africa(5.00%). There are total about 1000+ people in our office. 2.How can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment; 3. Are you trading company or manufacturer? We are factory.Due to the factory direct sales so we can offer the lowest price. 4.Why should you buy from us not from other suppliers? Fluido is one of the biggest manufacturers and exporters of pipeline products in China. We specialize in pipeline products, and casting and forging products, we have more than 15years experience for production, quality control and export. 5.How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. 6. What services can we provide? Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery; Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CHF; Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash; Language Spoken:English,Chinese,Spanish Brass Ball Valve 1/4" to 4" 600PSI NPT BSP Thread Hot Forging
